Simplex 4001 Series Quick Start Manual

®
ULC Listed
FEATURES
•
Four monitor zones
•
Up to 18 two-wire smoke detectors per zone
•
Signal circuits — 2 class B or 1 class A —
field configurable
•
Selectable alarm verification
•
Self-contained audible trouble signal
•
One normally open city contact
•
One form C alarm auxiliary contact
•
One form C trouble contact
•
Transient suppression for municipal
connections on power supply
•
Automatic battery charger
•
Standby batteries
•
Surface or semi-flush mounting
•
Alarm/trouble system walk test
•
Alarm resound
•
Battery supervision
•
Earth ground supervision
•
Brown out supervision of AC power
•
Automatic signal silence
•
DIP switch selectable programming
•
End-of-line devices and batteries included
•
ULC Listed to CAN-ULC-S527-99
OPTIONS
Option Board - supervised annunciator output
•
- auxiliary resettable power
- non-silenceable trouble contact
Semi-flush trim kit
•
External battery & cabinet for 60 hour backup
•
©2003 SimplexGrinnell Canada Ltd.
Fire Alarm Systems
Fire Alarm Controls
Simplex
®
ZONE
ZONE
1
2
3
4
FIRE ALARM CONTROL
PANNEAU DE CONTROLE AVERTISSEUR D'INCENDIE
4001-9304C
SPECIFICATIONS
Input ..................................1.2A @ 120VAC 60 Hz
Humidity .................85% non-condensing @ 30°C
Temperature .......................................0°C to 49°C
Weight...............Approximately 10kg c/w batteries
Colour ..........................................................Beige
Knockouts .......................................................1/2"
Life Alarm
4001-9304C
ALARM TROUBLE
ALARME TROUBLE
AC POWER ON
ALIMENTATION
SYSTEM TROUBLE
TROUBLE SYSTEM
SIGNALS SILENCED
ARRET ALARME
S01575-110-2 10/03
