Phonic POWERPACK 410 User Manual

POWERPACK 410
INTRODUCTION
For those who enjoy an easy set up for complete PA
systems, Phonic proudly presents a superb solution.
With the long-time popular Powerpod 410, accompanied
by two newly designed two-way 10" speakers, a low
impedance professional microphone (with clip, cable
and carry-pouch), and two 20 foot speaker cables, the
PowerPack 410 may just draw a conclusion to your
search for the ultimate system.
This complete PA package includes:
1x Powerpod 410 powered mixer
2x SEM710 two-way 10" stage speakers
2x 20ft speaker cables
1x mic with clip, cable and carry pouch
FEATURE
Powerpod 410 Powered Mixer
Built-in 100 Watt power amplifier
4 mic/line input channels
Variable digital delay
XLR and 1/4" TRS phone input jacks
Super musical 2-band EQ at mono channels
Additional 1/4" stereo jack for external signal to use
the built-in power amplifier and sending Main output
to external power amplifier
Tape In and Record out for CD or tape player
Two 1/4" phone jacks for speaker connection
Rugged wooden box with carpet protection
2x SEM710 Two-Way Stage Speakers
Versatile use as a floor monitor or mounted as a
raised sound reinforcement speaker
Power handling (RMS/program ): 80 / 160 Watts
Frequency response: 65Hz ~ 20KHz
Sensitivity : 96 dB SPL (1 W / 1 M)
10" heavy-duty woofer & piezo tweeter
8 ohms nominal load
Built-in handle
35 mm stand adapter built-in
Dual 1/4" phone jacks
