Variquest Cutout Maker 1800 Unpacking And Setup Instructions

Step 1. Unpack the Cutout Maker
The Cutout Maker and accessories are packed in a cardboard carton with foam
padding for protection during shipment. Carefully unpack the items and keep
the packing materials. If you need to ship the Cutout Maker in the future,
repack the system as indicated below.
Due to the weight of the unit, we recommend that 2 people lift the
Cutout Maker from the carton. To avoid personal injury, use proper
lifting techniques when removing the Cutout Maker from the carton.
Cardboard
Cover
Packing
Foam
CM1800
Foam
Cradle
Shipping
Container
WARNING
End Cap
(rear, notch)
End Cap
(front)
Blade
Assembly
Foam
Gantry Rail
Foam
(Instructions Continued on Other Side)
Unpacking and Setup Instructions
1. Remove the cardboard cover and packing foam.
2. Remove the front and rear endcaps.
3. Carefully remove the Cutout Maker from the foam cradle and shipping
container.
4. Open the Cutout Maker cover and remove the foam from the blade
assembly and gantry rail.
Note: When repacking: 1) Position the blade assembly and gantry rail
foam pieces correctly so they make a snug fit. 2) Position the endcap
with the notch on the rear side of the gantry and the other endcap on
the front. 3) Position the packing foam so it is snug against the gantry
rail and without a gap.
Step 2. Verify the Package Contents
After unpacking, verify that all of the following items were included in the Cutout
Maker box. For additional information, refer to the VariQuest
1800 User's Guide located at www.variquest.com.
USB Cable
Electrical Power Cord
Maintenance Kit
Cutout Maker 1800
®
Cutout Maker
Cutout Maker 1800
