VariQuest® Design Center 2300D Unpacking and Setup Instructions

Step 1: Unpack the box and check the contents

The VariQuest Design Center 2300D (DC2300D) and its
accessories are packed in a cardboard carton with foam padding
for protection during shipment. Carefully unpack the system and
keep the packing materials for future use.
Verify the items in the box. If an item is missing or appears to be
damaged, contact your authorized VariQuest Dealer immediately.
Included in the box:
- All-in-one Touch PC - Power Cord

Step 2: Attach the stand arm to the base

1. Attach the stand arm to the base with the two hand screws
located in the bottom of the base.

Step 3: Attach the stand

- Keyboard & Mouse
(optional*)

Step 4: Connect the power cord

1. Connect the female end of the power cord into the power
2. Connect the other end of the power cord to an outlet (2).
3. Connect the round end of the power cord to the power supply
(continued on reverse)
1. Place the Design Center facedown on a soft flat surface. We
recommends that you set down a soft cloth to protect the
screen surface.
2. Engage the hooks in the top of the
stand in the two large holes in the
upper part of the back of the
computer (1).
3. Rotate the stand down
until it clicks into
place (2).
supply brick (1).
connector on the back of the DC2300D (3).
