  • Page 1 Manual Detailed Table of Contents 1. Safety Precautions Digital 2. Control elements and connections Terrestrial Receiver 3. Remote Control 4. Connecting and operating the receiver IDL 1000 T 5. Trouble-shooting Technical data Index (A-Z)
  • Page 2: Table Of Contents

    Table of Contents 1. Safety Precautions ......................2. Control elements and connections ................3. Remote Control ......................4. Connecting and operating the receiver ............... 4.1 Connections ..........................4.2 On/Off switch ........................... 4.3 Programme selection ......................4.4 Subtitling activation ..………….................... 4.5 Zapping ............................ 4.6 Teletext …..…..........................
  • Page 3: Safety Precautions

    1. Safety Precautions This set-top box has been manufactured in accordance with international safety standards. For your own safety, youshould read the notes on safety precautions carefully, and take note of them, before operating your new receiver. For your own safety, please be sure to follow these safety precautions: Mains power supply: Connect the unit only to a mains power supply that has the following characteristics: 90-260 V AC, 50-60 Hz Connection to the TV set and video recorder: Here, too, the receiver must be disconnected from the...
  • Page 4: Control Elements And Connections

    2. Control elements and connections View of the front panel Control elements on the front panel Connections on the rear panel Infra-red sensor (Remote Control) VCR Scart Receives signals from the remote control unit Facility for connecting a video recorder On/Off Led TV Scart Indicates if the receiver is On or Off...
  • Page 5: Remote Control

    3. Remote Control Function keys on the remote control unit The keys on the remote control can be divided into groups: - Function keys that directly control a specific function (these keys have a double functionality according to the situation) - Navigation keys - Numeric keys 0-9 On/Off (Standby)
  • Page 6: Connecting And Operating The Receiver

    4. Connecting and operating the receiver 4.1 Connections Your digital receiver provides a multitude of possible connections to other appliances. Here we list the most important options available. 4.1.1 Connection to the terrestrial antenna The digital receiver is connected directly to a terrestrial antenna on the ANTENNA IN connector (see page 4, connections on the rear panel item 3).
  • Page 7: Programme Selection

    4.3 Programme selection 4.3.1 Using the directional Up/Down or Ch+/Ch- keys Menu You can move up or down the programme list one slot at a time by using the two Ch+/Ch- or Up/Down keys on the remote control unit. When an interactive TV application is active, only the Ch+/Ch- keys do allow zapping as the Up/Down keys can have another functionality within the interactive-TV application.
  • Page 8: Zapping

    4.5 Zapping Various options exist to facilitate quick switching between programmes: a) Fast zapping using the directional keys Ch+/Ch- and Up/Down: Press the directional Ch+ or Up key to select the next higher programme in the programme list and the directional key Ch- or Down to select the next lower programme in the list.
  • Page 9: Calling Up The Main Menu

    4.7 Calling up the Main Menu Main Menu The receiver can now be individually configured, using the on-screen menu display. 1 TV Guide Personal Planner Press the ”OK/Menu“ key on the remote control. The Main Settings Menu will be displayed. Default Settings Exit Now use the directional keys to select the line “Settings“,...
  • Page 10: Programme Search

    4.8 Programme Search Settings Using the “OK/Menu“ key, call up the Main 1 User Preferences Menu, select the sub-menu “Channel Search“ and an 2 Channel Search automated channel search process starts. 3 Audio / Video Settings 4.9 Product information Searching for channels Please Wait...
  • Page 11: Personal Planner

    4.11. Personal planner Personal Planner This personal planner function allows defining events and reminders. The receivers will zap then automatically to these Wed May 22nd 2002 events or remind them to you. To activate it, select “Personal Planner” from the Main Menu. Select first a date, during which you want to set an event and press the blue information key to add a reminder event and then follow the instruction in the information bar at the...
  • Page 12: Trouble-Shooting

    5. Trouble-shooting Problem Possible cause Solution No box reaction Mains power cable not connected Check mains cable and plug to mains No sound, no picture Connect the antenna to the right antenna may not be correctly connector. connected. Sound OK, no picture Scart cable defective, or not Check Scart connection Switch back to TV operation...
  • Page 13: Technical Data

    Technical Data OSD / Languages OSD with guiding menu for installation and information,Control – Delete and Edit function. Front Panel Display Led On/Off Control IR Sensor Front end (RF Input) Input Connector 1 x IEC 169-2 Female Loop-through Output Connector 1 x F-type Input Frequency Range 47-862 MHz...
  • Page 14 CPU & Memory Channels Main Processor 32 Bits host CPU @ 81 MHz Flash Memory 2 Mbyte SDRAM 16 Mbytes Channel Scan Automated for all DVB programs, semi-automated or manual Channel Memories 999 channels, Last Station Memory Remote Control Operating Frequency / Distance 36 kHz, / 10 Meters max Code RC 5...
  • Page 15: Index (A-Z 40)

    Index (A-Z) Antenna 6 Remote Control 5 Audio/Video Settings 9 Reset 11 Batteries 5 Safety Precautions 3 Software Download 10 Switch off 6 Channel Search 10 Connections 4 Control elements 4 Technical Data 13 Trouble-shooting 12 TV set 3,6 Default Settings 11 Video recorder 4,6 Frequency 13 Function keys 5...
