I N S T A L L A T I O N I N S T R U C T I O N S
The Command Access Latch Pullback Mortise Lock retracts the latch for push/pull operation. These
LPM
A.
U.S. Customer Support
1-888-622-2377
LPM Series
instructions cover all series from LPM110-LPM188.
72" WIRE HARNESS
B.
L PM S er i es I ncl ud es
A.
LPM Mortise Lock
B.
PM300
C.
2- Power Leads
Visit our website for more details
www.CommandAccess.com
C.
(3-PRONG)
72" WIRE HARNESS
PM300
72" WIRE HARNESS
(3-PRONG)
24 VDC
C.
(2-PRONG)
Power Supply
Canada Customer Support
1-855-823-3002
Doc # xxxxx rev.x
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Command access LPM110
Summary of Contents for Command access LPM110
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S The Command Access Latch Pullback Mortise Lock retracts the latch for push/pull operation. These instructions cover all series from LPM110-LPM188.
- Page 2 Standard Placement Module Ceiling Tile Hinge Pocket Option Only LPM1 Series Installation Example Standard Placement Optional Placement Note: For LPM1 series option placement is only recommended for Hollow metal doors. For wood doors, use standard placement above ceiling tile or in junction box. 1.
- Page 3 For Lever Control Solenoid on LPM models 183-188 Only All other models skip to next page Step 1 - The door must be preped according to origional manufactures Step 4 - Connect the wires exiting the mortise pocket to the template, machined with a 3/8”...
- Page 4 Handing Instructions for LPM STEP 1: Locate the handing screw. This screw is used to hand the STEP 2: To hand the latchbolt, remove the faceplate. Pull the handles. The Locking side is opposite the screw. latchbolt out of the chassis and rotate, then release. The latchbolt is spring loaded and will return on it’s own.
-
Page 5: Specifications
Troubleshooting & Diagnostics • Check the Module is on High Output. • Confirm that power supply is a Command Access PS1, PS5-4, or PS5-6 Visit our website for more details U.S. Customer Support Canada Customer Support 1-888-622-2377 1-855-823-3002 www.CommandAccess.com...
