Typ: KT 1800, LGR 2500, LGR 6000 COM, LGR 7000 HEYLO GmbH, Im Finigen 9, 28832 Achim, erklärt, dass die genannten Maschinen, wenn sie gemäß Bedienungsanleitung und nach den anerkannten Regeln der Technik installiert, gewartet und gebraucht werden, den grundlegenden Sicherheits- und Gesundheitsanforderungen der Richtlinie „Maschinen“, sowie folgenden Bestimmungen und Normen entsprechen.
Luftentfeuchtern kann auch dazu beitragen, sekundäre Schäden durch eine hohe Luftfeuchtigkeit präventiv zu vermeiden. Um optimale Ergebnisse zu erzielen, verwenden Sie den LGR 6000 com mit um den zu trocknenden Bereich herum aufgestellten HEYLO Turbo Dryer oder ACE Lüftern. Die Lüfter tragen dazu bei, Wärmeenergie zu verteilen.
Trocknungstemperatur beträgt 20 bis 29 ° C. Dazu kann der Einsatz des Heizungs- und Lüftungssystems (Heizung und Klimaanlage) notwendig sein. Sollten am Standort keine Heiz- und Kühlmöglichkeiten vorhanden sein, so wenden Sie sich bitte an HEYLO. Ein Fachmann wird Ihnen dabei helfen, eine angemessene Lösung zu finden.
Sie bitte 5 Minuten vor dem erneuten Einschalten des Gerätes. Andernfalls wird es sich wieder abschalten. Schalten Sie das Gerät ein. Das Bedienfeld auf dem LGR 6000 COM besteht aus einem Display und einem Tastenfeld mit vier Tasten. Drücken Sie AN/AUS, um das Gerät einzuschalten.
Page 6
ABLASSPUMPE. Drücken Sie ABPUMPEN, um das Wasser aus dem Kondensatbehälter der Pumpe manuell zu entleeren. HINWEIS: Drücken Sie die Taste ABPUMPEN jedes Mal, bevor sie das Gerät bewegen. Während des normalen Betriebs wird die Ablasspumpe alle 6 Minuten automatisch aktiviert beziehungsweise jedes Mal, wenn der Behälter voll ist. Das Display zeigt PUMPE LEERT mit einem Countdown an.
0,0 A Zeigt die Stromaufnahme des Kompressors in Amper. Fehlermeldungen Falls die interne Gerätediagnose des LGR 6000 COM ein Problem bemerkt, so zeigt das Gerät eine Fehlermeldung an. Weitere Informationen erhalten Sie im Abschnitt „Fehlermeldungen“. 7. Wartung ACHTUNG! Gefahr vor Stromschlag! Ziehen Sie vor allen Instandhaltungsarbeiten den Netzstecker des LGR 6000 COM.
Page 8
Prüfen und reinigen Sie den Filter nach Bedarf. Achten Sie darauf, dass der Filter jederzeit sauber ist, um die innen liegenden Bauteile vor Staub und anderen Partikeln zu schützen. LGR 6000 COM ist mit einem High-Air-Flow-Filter ausgestattet. Der Filter kann abgesaugt und bis zu dreimal erneut benutzt werden.
Abbildung F Abbildung G Drücken Sie nun den Verdichter ein wenig nach vorne und ziehen Sie die obere Befestigungsplatte der Pumpe heraus. Siehe Abbildung H. Abbildung H Abbildung I Abschließend kann der untere Pumpenblock heraus genommen werden. Siehe Abbildung I. Die Auffangwanne der Kondensatförderpumpe sowie der Pumpenblock können nun gereinigt werden.
Vorgehen notwendig. Sollte die Fehlermeldung erneut erscheinen, so probieren Sie bitte die Lösung unter „Erklärung“ aus. Sollte das Problem dadurch nicht gelöst werden, so wenden Sie sich bitte an die HEYLO Kundendienstabteilung. A N Z E I G E D E S E R K L Ä...
Erhöhen Sie die Raumtemperatur. Luftdurchfluss im Gerät ist Prüfen Sie Filter und Rohrschlangen. beschränkt. Reinigen Sie diese gegebenenfalls. 11. Technische Daten Modell LGR 6000 COM F413-230V Kältemittel / Menge R 410a / 529 g Gewicht 30 kg Abmessungen (H × T × B) 318 ×...
Page 15
KT 1800, LGR 2500, LGR 6000 COM, LGR 7000 HEYLO GmbH of Im Finigen 9, D-28832 Achim, Germany, declares that, if they are fitted, maintained and used in conformity with the operating instructions and the generally accepted engineering standards, the machines mentioned are in keeping with the fundamental safety and health requirements of the “Machine Ordinance”...
The use of air dehumidifiers may also contribute to prevent secondary damage by high air humidity. In order to obtain a perfect result, use the LGR 6000 COM along with the HEYLO Turbo Dryer or ACE air mover set up in the area to be dried. The air mover helps to distribute the thermal energy.
If the location does not provide any heating and cooling possibilities, please get in touch with HEYLO. A specialist will help you find a suitable solution. Please get in touch with HEYLO for more information on a perfect drying environment.
Attaching the dewatering hose The pump of LGR 6000 COM is connected by a dewatering tube made of plastic. The hose can be fastened by a Velcro tape which is located on the side of the unit. Place the unconnected hose end into a container, sink, bucket or place outside or everywhere where the water can flow off safely.
Page 19
DRAIN PUMP Press DRAIN to manually remove the water from the condensate tank of the pump. NOTES: Press the DRAIN key every time before moving the unit. During normal operation, the drain pump is activated automatically every six minutes or every time when the container is full. The display shows PUMP DRAINING with a countdown.
NOTES: To facilitate matters, the same number is rendered on the barcode label as on the control panel. Press to display the following values: SENSOR TYPE, SENSOR REVISION and SENSOR CONF REV. For the diagnosis of a problem you can ask a HEYLO after-sales technician for his or her values. CURR CONSUMP 0.0 A Display the current consumption of the compressor in ampere.
Page 21
Check and clean the filter as required. Make sure that the filter is always clean in order to protect the internal component parts from dust and other particles. LGR 6000 COM has been fitted with a high-air flow filter. The filter can be vacuumed and can be used up to three times. Do not wash the pre-filter.
Fig. F Fig. G Now press the compressor forward a little and pull the upper fastening plate out of the pump. cf. Fig. H. Fig. H Fig. I Subsequently the lower pump block can be taken out. cf. Fig. I The collecting trough of the condensate feed pump as well as the pump block can be cleaned now.
In this case no other procedure is required. If the fault message appears again, please try the solution rendered in chapter “Explanation”. If the problem cannot be solved, please get in touch with HEYLO after-sales service department. Display of the control...
Check the filter and the pipe coil. Clean Air flow rate in the unit is them if necessary. limited. 11. Technical data Model LGR 6000 COM Type F413-230V Coolant / quantity R 410a / 529 g Weight 30 kg Dimensions (H ×...
Page 27
DE02-01646 Position / article number Description DE02-01713 Replacement blower 230V 79W 2630RPM DE03-00131 Rubber foot DE03-01755-02 Handle 1306032 Replacement filter DE08-01716-01 Temperature and moisture sensor DE08-01918 Vaporiser DE08-01919 Condenser DE08-01920-06 Housing - upper part orange DE08-01921-09 Housing - lower part grey DE08-01930 Protective grille - suction side DE08-01949...
