Artnet-DMX Control System
Artnet-DMX-8
Manual
www.ltech-led.com
Product Introduction
Ethernet Control System based on the Artnet protocol.
Set different network segments to avoid multiple sets Artnet data interference.
Convert the Artnet network data package into DMX512 data.
Adopting high-speed ARM processor, stable and reliable.
Supports RJ45 network interface and 3-pin XLR DMX512 output interface.
With LCD screen display and 4 buttons, convenient operation, intuitive settings.
Standard 1U(19") chassis architecture, convenient installation in the standard cabinet.
Provides 8 standard DMX512 data output port.
Compatible with the light software based on Artnet Protocol, control stage lighting
and LED lighting simultaneously.
Connect up to 256 DMX universes to one network.
10/100Mb Ethernet port.
Data activity indicators.
Configurable DMX output refresh rates.
Manage Artnet on broadcast mode or unicast mode.
Widely used in the LED dot matrix and the stage lighting control network in needing
lots of DMX512 data.
Suitable for TV station recorded scene, stage performances, entertainment and so on.
