Summary of Contents for Telular PHONECELL SX6P GSM
- Page 1 SX6P GSM ® HONECELL • Fixed Wireless Phone 850/1800/1900 MH GSM (T 900/1800/1900 MH GSM (T MODELS ANUAL 12/15/04 Part Number 56031701...
- Page 2 Serial Cable or USB Cable (SX6P-300G series only) Fixed Wireless Phone This manual is for use with all SX6P-200G and SX6P-300G series deskphones only. To determine which model of phone you have, pick up the phone and view the label underneath for verification. Phonecell SX6P GSM ®...
-
Page 3: Sx6P Menu Structure
SX6P MENU STRUCTURE Menu Phonecell SX6P GSM ® Phonebook Service Numbers View Names Add Name Settings Messages Received Messages Saved Messages Create Message Message Settings Voicemail Info Message Clock Set Alarm Clock Settings Set Time Set Date Set Time Zone Settings Phone Settings Audio Settings... -
Page 4: Contents
TERMS AND CONDITIONS FOR USE OF PHONECELL These Terms and Conditions are a legal contract between you and Telular Corporation for the title to and use of the Product. BY RETAINING AND USING THE PRODUCT AFTER RECEIPT OF IT, YOU AGREE TO THE TERMS AND CONDITIONS INCLUDING WARRANTY DISCLAIMERS, LIMITATIONS OF LIABILITY AND INDEMNIFICATION PROVISIONS BELOW. -
Page 5: Table Of Contents
TABLE OF CONTENTS QUICK CONNECTION GUIDE ...i SX6P MENU STRUCTURE...ii CONTENTS ...iii SAFE OPERATION INSTRUCTIONS...iii IMPORTANT NOTICES...iii SX6P SETUP...1 SIM Card Installation ...1 Battery Installation ...1 Battery Operation...2 Location and Setup...2 Connect the Handset ...2 Wall-Mounting ...3 Connect the SX6P to AC Power ...4 GETTING TO KNOW YOUR SX6P...5 Function Keys ...5 LCD Screen Icons...6... - Page 6 SUPPLEMENTARY SERVICES (NETWORK DEPENDENT) ...20 In-Call Options ...20 Call Divert (Forwarding)...20 Call Waiting...21 Multiparty Calling ...21 Caller ID Settings...21 Blocking Your Number (CLIR) ...21 Voicemail...22 Short Message Service (SMS) ...22 Information Messages ...24 Network Call Barring...25 DATA FEATURES ...26 Connect SX6P to a Computer ...26 Configure PC for Circuit Switched Data ...26 Automatic Baud Rate Fall Back Control ...26 Digital Fax Setup ...27...
-
Page 7: Sx6P Setup
4. Reinstall the battery access door using the screw - see Figure 3. Do not use batteries other than the included Telular battery pack with the SX6P. Using any other batteries may result in fire and/or other damage to the unit. -
Page 8: Battery Operation
Battery Operation The SX6P will recharge its battery pack when connected to AC power. If AC power is interrupted, the SX6P will continue to operate, using power from the battery. (Standby and talk-times will vary based upon phone usage during power interruption.) Location and Setup The SX6P comes with a standard spike antenna (TNC). -
Page 9: Wall-Mounting
Wall-Mounting 1. Remove the mounting clip from the cradle and re-insert it with the tab pointing up - see Figures 7 and 8. Mounting Clip in Cradle (tab up) Figure 7 – Handset mounting clip assembly. 2. Mark two hole locations 83 mm (3-1/4 inches) vertically apart and drill two holes into the wall. 3. -
Page 10: Connect The Sx6P To Ac Power
Connect the SX6P to AC Power 1. Connect the barrel connector of the power supply to the AC power input on the rear panel of the SX6P - see Figure 11. 2. Plug the AC power cord into the power supply. 3. -
Page 11: Getting To Know Your Sx6P
GETTING TO KNOW YOUR SX6P Function Keys Operation of the SX6P is accomplished through the function keys on the keypad of the unit - see Figure 12. LCD Screen - Displays icons, information, and menu options necessary to operate the SX6P. LCD Soft Keys - Provide access to the SX6P menu options and features. -
Page 12: Lcd Screen Icons
LCD Screen Icons Icons displayed on the LCD screen indicate the features in use, the status of the phone, signal strength and battery status - see Figure 13. Message - Displays when a new text or voicemail message has been received. Alarm - Indicates that the alarm feature has been set. -
Page 13: Call Functions
• To erase all digits, press and hold down the CLEAR key until all digits are erased. • To insert numbers, use the arrow keys. Redial the Last Telephone Number Dialed 1. Pick up the handset or press the SPEAKERPHONE key. The SX6P is now “off-hook.”... -
Page 14: Sx6P Basic Features
SX6P BASIC FEATURES Date and Time Settings The SX6P allows customization of the date, time, time zone, and time format (12 or 24 hour). Set the Date 1. Press the MENU key. 2. Select Clock. 3. Scroll to Set Date, then press the CHANGE key. 4. -
Page 15: Adjust Alert Tones
1. Press the SPEAKERPHONE key. A dial tone will be heard through the speaker and the Speaker icon will display. 2. Enter a telephone number, press the REDIAL key or press the NAME key to find a number you have previously entered into the Phonebook - see the Phonebook section of this manual for details about how to enter a number. - Page 16 Keypad Buttons for Text Entry (Multitap) There are three or four letters (as well as a number) assigned to each key on the telephone keypad. During text entry, pressing a key displays the first letter, then cycles through the other letters.
-
Page 17: Speed Dialing
Speed Dialing Speed dialing permits one-touch dialing for up to 10 telephone numbers stored in the phone book. 0 through 9 on the keypad are used for speed dialing. You must press and hold the corre- sponding key for 2 seconds to use speed dial. -
Page 18: Sx6P Additional Features
SX6P ADDITIONAL FEATURES Call Logs The SX6P stores the telephone numbers of the last ten outgoing calls and the last ten incoming calls with the dates and times of the calls. These numbers are displayed and can be dialed directly from the call log. -
Page 19: Language Selection
The SX6P can be customized with a personal greeting that displays when the SX6P is turned on. It can also be programmed to display your phone number. Store Your Telephone Number for Viewing 1. Press the MENU key. 2. Select Settings, then select Phone Settings. -
Page 20: Call Settings
Call Settings Minute Minder When turned on, the Minute Minder emits a low audible tone once every minute while a call is active. 1. Press the MENU key. 2. Select Settings, then select Call Settings. 3. Select Minute Minder, then select On or Off as desired. Call Timer When turned on, the Call Timer displays during an active call. -
Page 21: Network Settings
Network Settings Network settings allow selection of a desired network and addition of a network operator to the network list. Automatic Selection This option allows the SX6P to select the network automatically, based on the SIM Card account information. Manual Selection This allows you to see a list of networks in your area. -
Page 22: Sim Pin Setup
Add New Network If a known network is not on the list, it can be added. The Country Code, Network Code, and Network Name must be provided in order to add a network to the list. Once added to the network list, the network can be accessed via the Set Preferred Network option. -
Page 23: Handset Call Barring
Change SIM PIN1 SIM PIN1 must be enabled and a valid PIN must be entered before this menu item will appear. 1. Press the MENU key. 2. Select Settings, then select Security Settings. 3. Select SIM PIN1. 4. Select Change PIN. 5. -
Page 24: Restricted Dialing
Add Additional Prefixes 1. Press the OPTIONS key, then select Add. 2. Enter the new prefix, then press the OK key. Edit Current Prefixes 1. Press the OPTIONS key, then select Edit. 2. Use the arrow and CLEAR keys to edit the prefix. 3. -
Page 25: Closed User Groups (Cug)
Change Deskphone Lock PIN 1. Press the MENU key. 2. Select Settings, then select Security Settings. 3. Select Deskphone Lock, then select Change PIN. 4. Enter the old PIN, then press the OK key. 5. Enter the new PIN, then press the OK key. Closed User Groups (CUG) This feature depends entirely on your service provider and your account subscription. -
Page 26: Supplementary Services (Network Dependent)
Main Menu: Allows access to the Phonebook, Messages, or Call Log features. Call Divert (Forwarding) Call Divert sends incoming calls to another telephone number, even when the SX6P is turned off. Call Divert options include all calls, calls that come in when the line is busy, calls that are not answered after a specified number of seconds, or calls that come in when the SX6P is powered off or has lost the network signal (Not Found). -
Page 27: Call Waiting
Call Waiting Call Waiting enables notification of incoming calls when the SX6P is off-hook (whether during a call or during dialing). To respond to Call Waiting, press the FLASH key or the hook switch. Contact your service provider to activate Call Waiting. Enable/Disable Call Waiting 1. -
Page 28: Voicemail
Voicemail The VM key will blink and the envelope icon will display when there are new voicemail mes- sages. Contact your service provider to activate voicemail and for voicemail settings. Set Voicemail Access Numbers Typically, your service provider will set the voicemail access numbers for you. If they do not, con- tact them for the Home Mailbox , Roam Mailbox, Voice, and Message numbers. - Page 29 Forward Text Messages 1. View the desired message. 2. Press the OPTIONS key, then select Forward. 3. Enter the desired number or press the NAME key to select a phonebook entry. 4. Press the OK key. 5. To send the message, select Send Now. To save the message to send at a later time, select Send Later.
-
Page 30: Information Messages
Message Settings Message Center The message center number is used to retrieve your text messages. Contact your service provider for this number. 1. Press the SMS key, then select Message Settings. 2. Select Message Center, then enter the number that your service provider gave you. NOTE: If the number is already entered, press the OK key. -
Page 31: Network Call Barring
Network Call Barring The SX6P supports network call barring of incoming or outgoing calls and allows barring of spe- cific types of services, such as voice or data. Contact your service provider to activate network call barring. The following call barring options are available: •... -
Page 32: Data Features
DATA FEATURES (SX6P-300G series only) When connected to a personal computer (PC), the SX6P is capable of sending and receiving digital fax and data, sending and receiving email communications, and accessing the Internet. Data speeds may vary depending upon your cellular network. Connect SX6P to a Computer Use a RS232 serial cable to connect the DB-9 data port on the SX6P to the appropriate data port on your PC. -
Page 33: Digital Fax Setup
Baud Rate AT Commands The SX6P will accept AT commands to setup the port speed. If you want to change the SX6P port speed for a session or keep the change permanent, or if you just want to see the profile set- tings, use the following AT commands from a terminal application (like HyperTerminal). -
Page 34: Sx6P Troubleshooting
SX6P TROUBLESHOOTING Telephone Service is Not Working (Cannot make or receive calls) · Make sure the SX6P is powered on properly. · Make sure any equipment that is externally connected to the SX6P is correctly connected. · Test any externally connected equipment on a known system to verify operation. -
Page 35: Conformance Statements
Part 15 of the FCC rules. Changes or modifications not expressly approved by Telular Corporation will void your authority to operate the equipment per FCC part 15 paragraph 15.21.These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 36: Electronic Devices
Safe Operation Requirement The Phonecell ® SX6P must be either wall mounted or desk mounted and should not be operated when any person is within 203 mm (8 inches) of the antenna. Temperature Environment Operating Temperature: From -10°C to +50°C ; Up to 95% relative humidity (non-condensing). Storage Temperature: From -40°C to +60°C;... -
Page 37: Potentially Explosive Atmospheres
Potentially Explosive Atmospheres Turn your Phonecell ® SX6P OFF when in any area with a potentially explosive atmosphere. It is rare, but your Phonecell could cause an explosion or fire resulting in bodily injury or even death. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fueling areas such as gas stations;... -
Page 38: Warranty
(15) months from date of shipment from Telular. Telular, at its option, shall at no charge either repair, replace or refund the purchase price of the Product during the warranty period, provided it is returned by Buyer in accordance with the terms of this warranty to the Telular designated repair center. -
Page 39: General Provisions
LONG AN IMPLIED WARRANTY LASTS. VI. SOFTWARE PROVISIONS: Laws in the United States and other countries preserve for Telular certain exclusive rights for copyrighted Telular software such as the exclusive rights to reproduce in copies and distribute copies of such Telular software. Telular software may be copied into, used in and redistributed with only the Product associated with such Telular software. -
Page 40: Appendix A: Pc Serial Port Setup For Cs Fax And Data
PC SERIAL PORT SETUP FOR CIRCUIT SWITCHED DIGITAL FAX AND Requirements: · GSM account with your network service provider including a circuit switched data and fax facility. · PC, laptop, notebook with a RS232 serial port. · Windows 2000 or better. ·... - Page 41 4. The Install New Modem window may appear asking for the type of modem to install. Select "Other" followed by clicking the NEXT button. If this window does not appear, go to Step 5. 5. The Install New Modem window will appear. Then, click on the "Don't detect my modem option" followed by clicking the NEXT button.
- Page 42 6. The Install New Modem will update again to select the manufacturer and the modem model.Select “Standard Modem Types” from the Manufacture’s list. Select “Standard 19200 bps Modem” from the Models list then click next. 7. The Install New Modem will update to select the COM port. Select the COM port that will be connected to the SX6P then click Next.
- Page 43 8. The Modems Properties window should appear. Click on the Properties button. 9. The Standard 19200 bps Modem Properties window will open in the General tab. Set as shown with the COM port you have selected. 10. Then click on the Connection tab. Set as shown below. Phonecell SX6P GSM User Manual...
- Page 44 11. Click on the Advanced button. Set as shown. 12. Click on OK and Close to back out of each window. Your modem is now set up. NOTE: When using the SX6P for PC fax operation, make sure the modem connection uses software flow control.
- Page 45 Phonecell SX6P GSM User anual ®...
- Page 46 Phonecell SX6P GSM User Manual ®...
- Page 47 Phonecell SX6P GSM Technical Manual ®...
- Page 48 ©2004 Telular Corporation, all rights reserved. Part Number 56031701...
