Telular SX7P-300G series Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Telular SX7P
www.telular.com
Content
3
7
8
10
11
12
13
15
16
18
19
20
21
22
22
23
24
01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SX7P-300G series and is the answer not in the manual?

Questions and answers

Related Manuals for Telular SX7P-300G series

Summary of Contents for Telular SX7P-300G series

  • Page 1: Table Of Contents

    Content Telular SX7P For Your Safety Getting Started 1. SIM Card Installation 2. Insert Battery 3. Charging the Battery 4. Connect the handset 5. Wall Mounting 6. Connect the SX7P to AC Power 7. Phone Features 8. Function Buttons 9. LCD Display Icons 10.
  • Page 2 6. Using the Headset Basic Operations 1. Menu Structure 2. Special Features 3. Messages 4. Phonebook 5. Call History 6. Network Service 7. Profi les 8. Phone Settings 9. Organizer Data Features ( SX7P-300G series only) Specifi cations Warranty Statement www.telular.com...

  • Page 3: For Your Safety

    For your safety Telular SX7P For Your safety The SX7P functions as both a radio transmitter and receiver. When it is ON, the SX7P receives and sends out radio frequency (RF) energy. The SX7P GSM 900/1800 unit operates in the frequency ranges of 890 MHz to 960 MHz and 1710 MHz to 1880 MHz.
  • Page 4 Telular SX7P Check the laws and regulations on the use of cellular products in the areas where you drive. Some jurisdic- tions prohibit your using a cellular device while driving a vehicle. Even if your juris-diction does not have such a law, we strongly suggest that, for safety reasons, the driver use extreme caution when operating the cellular device while the vehicle is in motion.
  • Page 5 TERMS AND CONDITIONS FOR USE OF PHONECELL® PRODUCTS (“Product”) These Terms and Conditions are a legal contract between you and Telular Corporation for the title to and use of the Product. BY RETAINING AND USING THE PRODUCT AFTER RECEIPT OF IT, YOU AGREE TO THE TERMS AND CONDITIONS INCLUDING WARRANTY DISCLAIMERS, LIMITATIONS OF LIABILITY AND INDEMNIFICATION PROVISIONS BELOW.
  • Page 6 Product. INDEMNIFICATION OF TELULAR CORPORATION (“TELULAR”) YOU SHALL INDEMNIFY, DEFEND AND HOLD HARMLESS TELULAR FOR ANY OF THE COST, INCLUD- ING REASONABLE ATTORNEYS’ FEES, AND FROM CLAIMS ARISING OUT OF YOU, YOUR CLIENTS’ OR OTHER THIRD PARTIES’ USE OR OPERATION OF THE PRODUCT: (i) FOR MISUSE OR IN A MAN- NER NOT CONTEMPLATED BY YOU AND TELULAR OR INCONSISTENT WITH THE PROVISIONS OF THIS MANUAL;...

  • Page 7: Getting Started

    Getting started Telular SX7P Getting started 1. SIM Card Installation 2. Insert Battery 3. Charging the Battery 4. Connect the handset 5. Wall Mounting 6. Connect the SX7P to AC Power 7. Phone Features 8. Function Buttons 9. LCD Display Icons 10.

  • Page 8: Sim Card Installation

    Getting started Telular SX7P 1. SIM Card Installation The SX7P requires a Subscriber Identifi cation Module (SIM) for normal operation. The service provider supplies the SIM card, which carries the account information needed to operate the SX7P. The SIM compartment is on the back of the SX7P.
  • Page 9 Getting started Telular SX7P (4). Place the SIM card in to the SIM card shaped slot (5). Gently push the SIM card forward until it locks into position. Note: To remove the SIM push down on the locking tab and slide the SIM back.

  • Page 10: Insert Battery

    Getting started Telular SX7P 2. Insert Battery (1). Press the battery access door latch and open the battery access door located on the bottom of the unit; (2). Gently plug the battery cable into the connector; (3). Place the battery pack into the compartment to fi t.

  • Page 11: Charging The Battery

    Getting started Telular SX7P The SX7P phone is equipped with a rechargeable sealed Ni-MH battery. 3. Charging the Battery New batteries are shipped partially charged and should be cycled for best performance. “Cycling” is fully discharging and then fully charging the battery to obtain full capacity.

  • Page 12: Connect The Handset

    Getting started Telular SX7P 4. Connect the Handset Before you can use the SX7P, you must connect the handset cable. (1). Connect the longer end of the handset cable to the phone jack on the bottom of the phone; (2). Gently fi t the straight section of the cord in the snake-shaped channel to keep it in position;...

  • Page 13: Wall Mounting

    Getting started Telular SX7P 5. Desktop Mounting and Wall Mounting (1) Desktop Mounting Install the mounting bracket as shown on the right to form an extra angle to hold the phone to the best position. (2) Wall Mounting I. Install the mounting bracket as shown on the right to form an 0° angle in order to hold the phone up-right on the wall.
  • Page 14 Getting started Telular SX7P II. Remove the mounting clip from the cradle and re-insert it with the tab pointing up III. Mark two hole locations 83 mm (3-1/4 inches), or 100 mm (4 inches) vertically apart and drill two holes into the wall.

  • Page 15: Connect The Sx7P To Ac Power

    Getting started Telular SX7P (1). Connect the USB Type B connector of the power supply to the AC 6. Connect the SX7P to AC power input on the rear panel of the SX7P. Do Not Twist the Connector. Power (2). Plug the AC power cube into the wall socket.

  • Page 16: Phone Features

    Getting started Telular SX7P 7. Phone Features www.telular.com...
  • Page 17 Getting started Telular SX7P See Illustration on the left: • USB type B Connector On the back side of the phone. AC power input and (SX7P-300 Series)optional data connection • Handset • LCD (Liquid Crystal Display) Displays icons, information, and menu options necessaryto operate the SX7P.

  • Page 18: Function Buttons

    Getting started Telular SX7P 8. Function Buttons • On/Off Button Used to power unit On and Off, and also used as “Back” key • Message Button This key is used to access voicemail or to send an SMS • Hot Message Button This feature allows a pre-programmed SMS message to be sent.

  • Page 19: Lcd Display Icons

    Getting started Telular SX7P 9. LCD Screen Icons www.telular.com...

  • Page 20: Service Indication

    Getting started Telular SX7P 10. Service Indication • Full Service When powered on, the SX7P will display a wakeup banner (the SX7P- 300 Series models LCD screen and keypad backlight will also light). After a few seconds, the greeting and mobile carrier will display.

  • Page 21: Call Functions

    Call functions Telular SX7P call functions 1. Making Calls 2. Receiving Calls 3. Ending Calls 4. In-Call Functions 5. Conference Calling 6. Using the Headset www.telular.com...

  • Page 22: Making Calls

    Call functions Telular SX7P 1. Making Calls • Pick up the handset or press the Speaker button. The SX7P is now “off-hook.” • Listen for dial tone. • Dial the phone number. The dialed number will be displayed. The name will also be displayed if it is stored in the phonebook.

  • Page 23: Ending Calls

    Call functions Telular SX7P When there is an incoming call, the SX7P rings, an incoming call notifi ca- tion displays the call type and Caller ID information (if available). • Pick up the handset or press the Speaker button. • Begin talking.

  • Page 24: Conference Calling

    Telular SX7P microphone. Place a Call on Hold • While in a call, press Flash button, or press Option (left soft key) and select Hold. • The display will change from A(activated) to H(Held). • To reactivate the call, press Flash button again. or press Option (left soft key) and select Unhold.

  • Page 25: Using The Headset

    Telular SX7P conference. Swap: Change the selected party being placed on hold in the call, the caller on hold will be displayed. Phone book: Using this option, user can perform the phone book operations including: access to the list of contacts, addnew entries, copy or delete, etc.
  • Page 26 Call functions Telular SX7P now active. To switch back to the handset, unplug the headset from the headset jack. Note: When making a call using the Speaker button, connect the Head- set after the Speaker button has been pressed and call initiated.

  • Page 27: Basic Operations

    Basic Operations Telular SX7P Basic oPERATIONS 1. Menu Structure 2. Special Features 3. Messages 4. Phonebook 5. Call History 6. Network Service 7. Profi les 8. Phone Settings 9. Organizer www.telular.com...

  • Page 28: Call History

    Basic Operations Telular SX7P 1. SX7P Menu Structure Menu Messages Phone Book Call History Network Profi le Phone Settings Organizer Service (1). Read (1). List (1). Missed Calls (1). Divert (1). Normal (1). Languages (1). Alarm (2). Write (2). Add New Entry (2).
  • Page 29 Basic Operations Telular SX7P (1). Shortcuts 2. Special Features (1). Shortcuts In idle Mode: (2). Key lock and unlock Up Arrow Key: Profi les menu Down Arrow Key: Phone Book menu Left Arrow Key: Messages menu Right Arrow Key: Call History menu Center Key: FM Radio, and selects highlighted menu items (2).
  • Page 30 Basic Operations Telular SX7P 3. Messages The shortcut to Messages is the Left arrow key and the Message Button in idle mode. (1). Read (2). Write (1). Read (read a message) (3). Delete All When a message is received, New Messages will be displayed on the (4).
  • Page 31 Basic Operations Telular SX7P iii. Send a message to the number. You can also press the Send key directly to call this number. • Call Number — Call the number that sent you this message. (2). Write (Write and send a message) I.
  • Page 32 Basic Operations Telular SX7P • Discard — Erase the text clipboard. IV. To send the message, select Send, enter the recipient’s phone num- ber or select Names to retrieve a number from contacts, and select Send. Note: When sending messages, your device may display the line Sending Message.This is not an indication that the message has been...
  • Page 33 Basic Operations Telular SX7P I. From Menu, select Messages > Settings > Service Cent. II. If the box in the display is empty or contains an incorrect number, enter the number given by your network operator, and select OK. If the box in the display contains the correct number, select OK. A mes- sage appears in the display confi...
  • Page 34 Basic Operations Telular SX7P List of cell broadcast fi lter names and parameters set. (7). Voice Mail This option enables you to answer the voice mail. You should apply for this service from your network operator fi rst, then you can use this func- tion.
  • Page 35 Basic Operations Telular SX7P You can save the phone numbers and corresponding names into the 4. Phone Book (1). List phone memory or SIM Card of your phone. Your phone memory allows (2). Add New Entry you to store 500 names and phone numbers in total. The length and (3).
  • Page 36 Basic Operations Telular SX7P • Delete — Delete a name and its associated numbers. • Ringer — Assign a specifi c ringer tones to the contact numbers, pro- vided 10 user defi ned ringers and 9 default ring tones. (2). Add New Entry From Menu, select PhoneBook >...
  • Page 37 Basic Operations Telular SX7P Screen will suggest Edit or Back. Select Edit to edit the number. (5). Copy All From Menu, select PhoneBook > Copy All Select SIM to Phone to copy all entries from SIM card to the phone; or select Phone to SIM to copy all entries from the phone to the SIM card.
  • Page 38 Basic Operations Telular SX7P 5. Call History Call History stores information about the last 10 missed, 10 received, (1). Missed calls and 10 dialed calls. It also adds the total duration of all calls. When the (2). Answered calls number of calls exceeds the maximum, the most recent call replaces the (3).
  • Page 39 Basic Operations Telular SX7P Store Number — Enter a name for the number and save it to contacts. Send message — Send a message to the number. Details — Display the date\ number and time of the call. Delete — Clear the number from memory.

  • Page 40: Network Service

    Basic Operations Telular SX7P 6. Network Service (1). Divert (Netwrk Dependent) (1). Divert I. Not Reachable (2). Network Sel. This allows you to forward incoming calls when your phone is power off or (3). Call barring in an area where the network is unreachable.
  • Page 41 Basic Operations Telular SX7P • From Menu, select Network service > Divert > All Calls • Scroll to operate these options: Status, Set, Cancel V. Cancel All Cancel any call forwarding options you may have set. From Menu, select Network service > Divert > Cancel All to cancel all settings.
  • Page 42 Basic Operations Telular SX7P operator. From Menu, select Network service > Call Barring, the menu options are as the following: I. Outgoing — When this option is activated, you are unable to dial any number II. Intern. Calls — When this option is activated, you are unable to dial any international number.
  • Page 43 Basic Operations Telular SX7P network password. (4). Call Waiting If supported by your network operators, call waiting notifi es you of an in- coming call even while you are in a call. You can accept, reject, or ignore the incoming call.
  • Page 44 Basic Operations Telular SX7P Attach is not selected. Detach - User can detach the GPRS service manually. SMS - User can send the SMS message over GPRS service. Auto Attach - Phone Automatically Attach/Detach GPRS service when switch on or off the phone.
  • Page 45 Basic Operations Telular SX7P 7. Profi le User can activate any one of the profi le settings and also customize the melody and volume settings.The shortcut for Profi les is the Up arrow in (1). Normal idle mode. (2). Silent (3).

  • Page 46: Phone Settings

    Basic Operations Telular SX7P 8. Phone Settings (1). Languages From Menu, select Phone Settings > Languages and one of the follow- (1). Languages ing: (2). Back Light • English (3). Call Timer • Spanish (4). Dial Tone • French (5). Minute Minder •...
  • Page 47 Basic Operations Telular SX7P The call timer is displayed once the call is connected and will increment per second. The call timer will stop when the call is ended. You can program the call timer display options set in menu.
  • Page 48 Basic Operations Telular SX7P mm/dd/yyyy. (7). Security I. FDN (Fixed Dialing Number) PhoneBook Once you set up and activate the FDN, this secondary phone book turns on to take the place of the regular Phone Book. Your phone can make calls only to those numbers that you have defi...
  • Page 49 Basic Operations Telular SX7P iii. At the prompt, enter the new PIN code again, and select OK. III. Change PIN2 The PIN2 code is required for features such as fi xed dialing. If you enter an incorrect PIN2 code three times in succession, the PIN2 code is blocked and you will have to enter the PUK2 code.
  • Page 50 Basic Operations Telular SX7P The FWP shall store that PIN and automatically enter it whenever the PIN is required so that the user does not have to enter it manually. VI. Personalization From Menu, select Phone Settings>Security>Personalization Personalization features check information stored in the FWP with that stored in the SIM.
  • Page 51 Basic Operations Telular SX7P (8). Auto Redial From Menu, select Phone Settings > Security > Auto Redial You can select On or Off. When this function is activated, your phone will automatically redial the number up to 10 times after 10 attempts the func- tion will be terminated.
  • Page 52 Basic Operations Telular SX7P tings. Note: The stored phonebook information and messages will not be affected by restoring the factory settings. (13). Service Settings From Menu, select Phone Settings > Service Settings Note: Service PIN is required to access Service Settings (default 1234).
  • Page 53 Basic Operations Telular SX7P From Menu, select Phone Settings > Service Settings > Dial Delay. After last digit dialing, phone will wiat for a period of time ( 1 to 10 sec- onds) and then automatically dial the number entered. The default value set to 3 seconds.
  • Page 54 Basic Operations Telular SX7P You can select On to activate and Off to deactivate the service PIN via menu item, also change the password for PIN. If Service PIN is active, user has to provide this PIN before entering into service setting options.

  • Page 55: Organizer

    Basic Operations Telular SX7P (1). Alarm 9. Organizer The Phone allows you to set an alarm clock that can be used on time or (1). Alarm every day. (2). Power On I. Alarm (3). Power Off From Menu, select Organizer > Alarm > Alarm (4).
  • Page 56 Basic Operations Telular SX7P The calculator adds, subtracts, multiplies, divides digits. Note: This calculator has limited accuracy and is designed for simple calculations. I. From Menu, select Organizer > Calculator II. In the calculator screen, enter the fi rst number in the calculation.
  • Page 57 Basic Operations Telular SX7P You can play the FM radio using the phone at selected preset channel. Play - Start the FM Radio at selected preset channel. Preset Channels User can store the 9 station presets. Select and Play - You can set 9 pre defi ned channels using Select and Play option.

  • Page 58: Specifi Cations

    Telular SX7P sPECIFICATIONS Air Interface Standard GSM Phase 2+ Transmit Power GSM 850/900: 2 watts DSM 1800/1900: 1 watt Frequency Ranges GSM 850 GSM 900 GSM 1800 GSM 1900 FWP Dimensions and Weight Metric: 175mm (W) x 170mm (L) x 96mm (H)
  • Page 59 AC-to-DC Charger (Included) Voltage:Input: 90 - 240 V. Outpu: 5.25 V. Frequency: 50/60 Hz Internal Battery Backup 3.6v rechargeable NIMH Talk time: More than 4 hours. Standby time: up to 14 days. Both depend on network conditions. *SX7P-300G series only www.telular.com...

  • Page 60: Warranty Statement

    I. WHAT THIS WARRANTYCOVERS AND FOR HOW LONG: TELU- LAR CORPORATION (‘Telular”) warrants to a distributor Buyer, or to a customer only if the customer is a Buyer directly from Telular, that the Products (including accessories) shall comply with the applicable Specifi -...
  • Page 61 Products manufactured by Telular and sold to Buyer. Telular assumes no obligation or liability for additions or modifi cations to this warranty unless made in writing and signed by an offi cer of Telular. Unless made in separate written agreement between Telular and Buyer, Telular does not warrant the installation, fi...
  • Page 62 (i) Costs and expenses, including without limitation handling, labor and transportation, incurred in returning Product for warranty service to Telular’s Repair Cen- ter. (j) Repair, programming or servicing by someone other than Telular.
  • Page 63 VI. SOFTWARE PROVISIONS: Laws in the United States and other countries preserve for Telular certain exclusive rights for copyrighted Telular software such as the exclusive rights to reproduce in copies and distribute copies of such Telular software. Telular software may be copied into, used in and redistributed with only the Product associated with such Telular software.
  • Page 64 Hereby, Telular Corporation declares that the SX7P 900/1800 MHZ (Dual Band) models are in compliance with the essential requirement and other relevant provisions of Directive 1999/5/EC. Hereby, Telular Corporation declares that the SX7P-200G 850/1900 MHZ (Dual Band) model is in conformance with all applicable FCC requirements.
