CHECKFIRE 110 Detection and Actuation
System Owners' Guide
CONTROL
MODULE
"DELAY/RESET/
SILENCE" BUTTON
This vehicle/equipment is monitored with a CHECKFIRE 110
Detection and Actuation System which is typically connected to
an ANSUL A-101 or LVS Fire Suppression System for 24-hour
®
fire suppression. The operator of the equipment should be
provided with hands-on training by Authorized ANSUL Distributors
or the end user.
This handbook is a quick-reference guide for basic operation
of the CHECKFIRE 110 system. Two buttons on the control
module and manual actuators provide operator control.
Fill-In System Information (as installed)
External Power Supply (vehicle battery, power panel, etc.):
Note: Internal backup power provides approximately 72 hours of power
during normal operating conditions.
Selected Time Delay Period (seconds):
Pressure Switch Auxiliary Operation:
VISUAL SEAL
PAGE 1
009151
"PUSH TO ACTIVATE/
ALARM WHEN LIT"
BUTTON AND LED
