- Page 1 PRESSURISED POND FILTER PF-8000 / 12000 / 20000 BIO-MECHANICAL FILTRATION BUILT IN STERILISER LARGE FILTER VOLUME PRESSURISED CLOSED SYSTEM SIMPLE USER FRIENDLY OPERATION...
- Page 2 To ensure your new pond filter is set up and running correctly, and to prevent any accidental damage or injury, please read and follow the below instructions carefully before using your product. SAFETY IMPORTANT! Disconnect the mains electricity supply before attempting any installation / maintenance of any kind.
- Page 3 To avoid injury, do not touch hot or moving parts such as, but not limited to · UV bulbs or impellers. During maintenance ensure all O-rings are present and intact. · If the appliance shows any signs of water leakage or the RCD unit switches ·...
- Page 4 ELECTRIC This unit comes complete with a generous supply of 3 core cable, however should any additional cable be required, the use of an approved waterproof cable connector with a proper rating is essential. A cord rated for less amperes or watts than the appliance rating may overheat.
-
Page 5: Installation And Use
INSTALLATION & USE Please read the below instructions carefully before beginning to set up your filter system. DO NOT CONNECT THE UNIT TO THE MAINS UNTIL SET UP IS COMPLETE AND UNIT IS FILLED WITH WATER. 1. Prior to installing the unit, examine the quartz sleeve and UV bulb to make sure these have not been damaged in transportation (see maintenance section). -
Page 6: Maintenance
UVC OPERATION Always ensure that the filter has water flowing through the unit prior to · operating the UV. Never look directly at the UV light when operational. · Check that the UV is operational visually using the UV indicator. ·... -
Page 7: Filter Maintenance
O-rings It is vital that O-rings are regularly inspected and replaced as the rubber watertight seal will perish over time, which may cause your unit to leak. Before replacing your o-rings, ensure they are well lubricated to ensure the seal is kept water tight. -
Page 8: General Maintenance
General Maintenance It is recommended that every 3-4 weeks you perform maintenance on the PF Filter. IMPORTANT! Disconnect mains electricity supply before handling or attempting maintenance. Opening your filter - the unit’s head can be removed by unfastening the head clasp on the side of the filter body. - Page 9 Remove the quartz sleeve from the unit by unscrewing two screws (as shown in the image below). Gently pull it out to remove it. The quartz sleeve can be coated in limescale build up in hard water areas. This should be carefully removed from the quartz sleeve and cleaned with a soft damp cloth.
-
Page 10: Replacing The Uv Bulb
Always change your UV bulb every twelve months regardless of it working or not, as its performance will lessen by this stage. The PF-8000 & PF-12000 use an 11w two pin PLS UV bulb. The PF-20000 uses an 18w two pin PLL UV bulb. -
Page 11: Parts Diagram
PARTS DIAGRAM BALLAST COVER QUARTZ SLEEVE QUARTZ SLEEVE O-RING 2 O-RING CLEANING INDICATOR UV BALLAST QUARTZ SLEEVE O-RING 1 HOSETAIL FILTER LID UV CLARIFIER... -
Page 12: Specifications
BOTTOM FILTER HOLDER PLATE HOLDER QUARTZ SLEEVE PROTECTOR FILTER SPONGE FILTER BODY O-RING CLASP TOP FILTER HOLDER FILTER BODY SPECIFICATIONS PF-8000 PF-12000 PF-20000 MODEL: UV POWER (WATTAGE): 9000 L/H 10000 L/H 10000 L/H MAX FLOW RATE: 380 x 380 x 420... -
Page 13: Troubleshooting
TROUBLESHOOTING UV Indicator is not Lighting Up If the UV indicator on the top of the filter lid is not lighting up follow these troubleshooting steps: 1. If you find that the UV light is not operational, check that you have power from the mains supply. - Page 14 Green Water or Cloudy/Brown Water? In order to correctly identify if you have green water or cloudy/brown water, a settlement test should be carried out. Take a jar of pond water and allow to settle for 24 hours. Green Tinge - If your jar is showing mostly green tinged water or has green particles floating in it, you most likely have a bit of an algae problem (follow the green water trouble shooting guide).
- Page 15 3. Reduce feeding. Overfeeding introduces a lot of organic waste and is one of the main causes for cloudy water problems. 4. Make sure to perform regular water changes, check your unit is clean and adequate for your pond size and do not overstock it. My filter is leaking 1.
-
Page 16: Warranty
WARRANTY The All Pond Solutions PF Filter range is guaranteed against defects in material or workmanship under normal pond usage and comes with 24 months warranty for all electrical parts. The warranty period commences from the date of purchase. If you require support on how to use your unit, replacement parts or if your filter develops a fault during the warranty period, please contact the supplier of your unit. - Page 18 All Pet Solutions Limited Trading as All Pond Solutions Unit 203 Riverside Way, Uxbridge, Middlesex, England, UB8 2YF...
