Summary of Contents for Squareled Othello
-
Page 2: Color
Manual | Othello 1. Safety Warning Squareled products are designed and manufactured to meet the requirements of People’s Republic of China and international safety regulations. Modifications to the product could affect safety and render the product non-compliant to relevant safety standards. Instructions pertaining to continued protection against fire, electric shock, and injury to persons are found throughout this manual. -
Page 3: Color
Manual | Othello 2. Fixture Overview 1) Lens 7) PowerCon in 2) LCD display 8) Fuse 3) Menu-button 9) Switch 4) Down-button 10) DMX 3-pin out 5) Up-button 11) DMX 3-pin in 6) Enter-button 12) DMX 5-pin in 13) DMX 5-pin out... - Page 4 Manual | Othello 3. Features Othello is a low power high output LED moving head. An incredibly efficient 480W white LED engine, provides output comparable with traditional 1200W discharge lamp fixtures. • Source: 480W White LED • CT: 6500K • Life: >20,000 hrs •...
-
Page 5: Color
Manual | Othello Attachment Instructions • Attach the Omega clamp on the bracket by tighten the M12 bolt on the bracket to the hole in the middle of the bracket. • Insert the quick-lock fasteners of the bracket into the respective holes on the bottom of the fixture. -
Page 6: Color
Manual | Othello 5. Dimensional Drawings... -
Page 7: Color
Manual | Othello 6. Mounting Orientations Be sure this fixture is kept at least 0.5m (1.6ft) away from any flammable materials (decoration etc.). Always use and install the supplied safety cable as a safety measure to prevent accidental damage and/or injury in the event the clamp is improperly installed or fails. -
Page 8: Color
The Othello fixture operates on standard DMX512 link controlled by a DMX console. The number of fixtures on a link will be determined by the combined number of channels required by all the fixtures. An Othello fixture requires a 26/33 channel footprint on a standard DMX512 link. Attach the fixture to the link using data-grade cable and 5-pin or 3-pin XLR cable connectors. - Page 9 Manual | Othello DMX Terminator For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, a DMX terminator on the last fixture of the link prevents data reflection, which can corrupt the data communication on the link.
- Page 10 Manual | Othello Head Reset Reset except P/T Reset Pan/Tilt Reset Reset only P/T Manual All Reset Reset whole light Channel For manual control of the attribute channels Stop Auto test programs , Auto program 1 Auto Test in order to test the functional components of the fixture, Auto program 2 the default status is “Stop”.
-
Page 11: Table Of Contents
Manual | Othello Dimmer fine 0-255 0-100% Strobe/Shutter Close 4-103 Strobe，Slow -> Fast 104-107 Open 108-207 Pulse: Slow -> Fast 208-212 Open 213-251 Random 252-255 Open Color Blank 8-15 Color 1 16-23 Color 2 24-31 Color 3 32-39 Color 4... -
Page 12: Gobo
Manual | Othello 20-29 Gobo 2 30-39 Gobo 3 40-49 Gobo 4 50-59 Gobo 5 60-69 Gobo 6 70-79 Gobo 1 Shake: Slow -> Fast 80-89 Gobo 2 Shake: Slow -> Fast 90-99 Gobo 3 Shake: Slow -> Fast 100-109 Gobo 4 Shake: Slow ->... - Page 13 Manual | Othello 191-194 Stop 195-255 Rotation(CCW): Slow -> Fast Gobo2 Rotating 0-127 Gobo2 Position 128-191 Gobo2 Rotation(CW): Fast->Slow 192-255 Gobo2 Rotation(CCW): Slow-> Fast Focus 0-255 0-100% Focus fine 0-255 0-100% Auto focus 0-31 Auto Focus Disable 32-59 Auto Focus 5m...
- Page 14 Manual | Othello Frost 0-255 0-100% CMY Function 0-127 Unused 128-255 CMY Fade CMY Speed 0-255 0-100% Cyan 0-255 0-100% Cyan fine 0-255 0-100% Magenta 0-255 0-100% Magenta fine 0-255 0-100% Yellow 0-255 0-100% Yellow fine 0-255 0-100% 0-255 0-100%...
- Page 15 Manual | Othello Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
