Page 2: Safety Instruction
Manual | Spectrum Mini 12x10W RGBAW 5in1 1. Summarization Summarization: Thank you for purchasing our PF1012 lighting. Please read these instructions carefully before begin and operate the fixtures according to these instructions to avoid any possible damages and accidents causes by misusage. -
Page 3: Outside Size Picture
Manual | Spectrum Mini 12x10W RGBAW 5in1 3. outside Size Picture 4. Main Function » high quality LED: low consumption, brightness, stable capability and long life » each color of LED with 16666 dimming. The refresh rate is over 400Hz. Flicker free for video and TV »... -
Page 4: Dmx Control Function
Manual | Spectrum Mini 12x10W RGBAW 5in1 5. DMX Control Function DMX Channel (4CH): channel DMX value Control Function Remarks 0-255 RGB color mixing 0-255 A Dimming 0-100% 0-255 W Dimming 0-100% Color Saturation 0-255 General dimming 0-100% purity DMX Channel (5CH):... - Page 5 Manual | Spectrum Mini 12x10W RGBAW 5in1 DMX Channel (10CH): channel DMX value Control Function Remarks Priority 0-255 General dimming 0-255 Red dimming 0——100% 0-255 Green dimming 0—100% 0-255 Blue dimming 0—100% 0-255 A 0-100% 0-255 W 0-100% 0-14 Dimming...
-
Page 6: Display Operation
Manual | Spectrum Mini 12x10W RGBAW 5in1 6. Display Operation » MENU : access the menu or return to a previous menu option » ENTER: select the current menu option » UP: menu selection or parameter increments » DOWN: menu selection or parameters decrease... -
Page 7: Menu Instruction
Manual | Spectrum Mini 12x10W RGBAW 5in1 7. Menu Instruction... - Page 8 Manual | Spectrum Mini 12x10W RGBAW 5in1 1. Operating instruction: MENU (UP/DOWN)+ENTER+(UP/DOWN)+ENTER Remark: Exp: Select the DMX mode, Here are the operation details: » Press the MENU, go back to the initial setting » Press UP/DOWN, display “Addr” » Press ENTER to change the content, the display will glinting at this moment »...
-
Page 9: Operating Control Instruction
Manual | Spectrum Mini 12x10W RGBAW 5in1 8. Operating Control Instruction Master/Slave: Master: The master should always work as a master as long as it is not set in a DMX mode whatever other modes it is. And it send out the signal so that the slave synchronous with it. To avoid the host signal and DMX512 signals interfere with each other, should cut off the DMX512 signals. - Page 10 Manual | Spectrum Mini 12x10W RGBAW 5in1 The Conversion between 3 pin and 5 pin XLR If the output cable of DMX512 controller is the 5PIN, please use 1pc 5PIN to 3PIN cable 10. Connecting picture Light connecting picture: Note: This product uses input and output power cord 1.5 m, copper core...
-
Page 11: Troubleshooting
Manual | Spectrum Mini 12x10W RGBAW 5in1 11. Trouble Shooting Problem Checking Way • Check the power source plug is in normal or not • Check the switch of the lights is off or on Can not turn on the light •... -
Page 12: Technical Specification
Manual | Spectrum Mini 12x10W RGBAW 5in1 12. Technical Specification • Input voltage: AC100-264V/47-63HZ • Output voltage: DC24V • Consume: 120W • Lamp Type: High Power LED(10w) • Lamp Spec: RGBAW 5-in-1 LED(12 pcs) • Refresh Rate: 400HZ • Life Span: 50000~100000 hours •... - Page 13 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
