Summary of Contents for Squareled MATRIX-5X10W
-
Page 2: Packing List
Manual | SquareLED UNIVERSAL LED BLINDER 5x10W RGBW 4in1 CREE 1. Introduction When you get this product, please take it from carton carefully to make sure whether all the accessories are in and damaged or not. When you find that there are any parts or wrong sign with the carton, or non-operation, please inform us and to keep the carton and shipping bill completely. -
Page 3: Dmx Channel
Manual | SquareLED UNIVERSAL LED BLINDER 5x10W RGBW 4in1 CREE 3. Features » 8 or 24 DMX channels. » RGBW LED light source (R5, G5, B5, W5) » life long is 50000-10000 hours. » Strobe: 0-16 Hz » Control mode: Auto, music, DMX512 mode »... -
Page 4: Fixture Linking
Manual | SquareLED UNIVERSAL LED BLINDER 5x10W RGBW 4in1 CREE 5. Setup Fixture linking When you control the light‘s master/slave or DMX 512 signal agreement, the lights can be connected by signal wire which the distance is ≤ 500 m,The maximum connect lights are 32pcs more or less, and adapt DMX light pair to segregate the signal zoom equipment, in order to protect the light’s signal won’t be interrupted by... -
Page 5: Menu Configure
Manual | SquareLED UNIVERSAL LED BLINDER 5x10W RGBW 4in1 CREE 6. Operating instructions Menu configure There are 4 buttons located in the bottom of the LED digital display when you check the menu configure of the bottom of light. Show as follow:... -
Page 6: User Configurations
Manual | SquareLED UNIVERSAL LED BLINDER 5x10W RGBW 4in1 CREE FLAS (Strobe setting) F0XX** (the total speed of strobe to be adjusted) FrXX (To adjust red brightness seperately) FgXX (To adjust green brightness seperately) FbXX (To adjust blue brightness seperately) -
Page 7: Dmx Channel Values
Manual | SquareLED UNIVERSAL LED BLINDER 5x10W RGBW 4in1 CREE Each master-slave group can be one and only light in master, ensure lights under this group without connec- tion with any DMX controller. To set DMX mode The light can connect to the DMX controller to receive its signal indication, which control by DMX controller. - Page 8 Manual | SquareLED UNIVERSAL LED BLINDER 5x10W RGBW 4in1 CREE Red (the first led) 0-255 0-100% Green (the first led) 0-255 0-100% Blue (the first led) 0-255 0-100% White (the first led) 0-255 0-100% Red (the second led) 0-255 0-100%...
- Page 9 Manual | SquareLED UNIVERSAL LED BLINDER 5x10W RGBW 4in1 CREE DMX Channel (8CH) Channel Value Function 0-255 Dimmer 0-100% Strobe 0-10 Shut 11-30 Neutral 31-200 Strobe with increase speed 201-250 Random Strobe with increase speed 251-255 Neutral Performance Function 0-15...
-
Page 10: Specifications
Manual | SquareLED UNIVERSAL LED BLINDER 5x10W RGBW 4in1 CREE 5. Specifications Input Voltage: AC100V - 240V 50 Hz/60 Hz Lamp resource: 5 pcs 10W RGBW 4in1 CREE LED Control model: Auto, sound, DMX512 signal Max temperature: 104°F (40°C) Data input/output: 3pin XLR-connection, anode socket Lens angle: 30°...
