Squareled BLADE 5 User Manual

48x10w - rgbw
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLADE 5 and is the answer not in the manual?

Questions and answers

Related Manuals for Squareled BLADE 5

Summary of Contents for Squareled BLADE 5

  • Page 2 BLADE 5 48x10W - RGBW USER MANUAL...

  • Page 3: Safety Instructions

    INTRODUCTION Thank you for having chosen our LED lighting Unpack the device, inside the box you should find: The fixture device One power cable One XLR connection cable This manual Please check carefully that there is no damage caused by transportation.

  • Page 4: Dmx-512 Control Connection

    the device should be earthed. The electric connection must carry out by qualified person. If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer or his service agent or a similar qualified person in order to avoid a hazard. Make sure that the available voltage is not higher than stated at the end of this manual.

  • Page 5: Display Menu

    in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 OHM resistor connected between pins 2 and 3,which is then plugged into the output XLR socket of the last fixture in the chain.
  • Page 6 Celsius Degree Temp Unit CS Fahrenheit Degree Value Clear DMX Status Value Hold Fan Speed Normal/ middle/ fast WDMX Mode Disable Display Mode Enable Temperature System Info Fixture Time 0-255 Green 0-255 Color Menu Blue 0-255 White 0-255 Set Red 0-255 White Balance Set Green...

  • Page 7: Main Functions

    Main functions 1. Address: Current DMX address A. Setting DMX address by button press ENTER button when show the address menu, then adjust the DMX address by pressing [UP] or [DOWN] button Press [ENTER] to confirm or press [ESC] to return to main menu. B.

  • Page 8: Display Mode

    Setting Dimmer Curve press ENTER button when show the dimmer curve menu, then select the dimmer curve by pressing [UP] or [DOWN] button Setting Cipher press ENTER button when show the cipher setup menu, then setup cipher by pressing [UP] or [DOWN] button Key mode press ENTER button when show the key mode menu, then select lock or unlock by pressing [UP] or [DOWN] button...

  • Page 9: Dmx Functions And Values

    press ENTER button when show the white balance menu, press Enter button to select the color mode, then adjust the color by pressing [UP] or [DOWN] button 6. Auto test press ENTER button when show the auto test menu, select test mode by pressing [UP] or [DOWN] button DMX functions and values 1 ch Mode...
  • Page 10 Value Function 0-255 0-255 Green 0-255 Blue 0-255 White 6 Ch Mode Value Function Blackout 8-15 Shutter Open 16-151 Strobe 152-175 Fade In 175-199 Fade Out 200-244 Random Strobe 245-255 Shutter Open 0-255 Master dim 0-255 0-255 Green 0-255 Blue 0-255 White 8 ChF Mode...
  • Page 11 9 ChF Mode Value Function 0-255 Master Dimmer 0-255 0-255 Fine Red 0-255 Green 0-255 Fine Green 0-255 Blue 0-255 Fine Blue 0-255 White 0-255 Fine White 10 ChF Mode 16BIT Value Function 0-255 Master Dimmer 0-255 Fine Master Dimmer 0-255 0-255 Red dimmer fine...
  • Page 12 175-199 Fade Out 200-244 Random Strobe 245-255 Shutter Open 0-255 Master dim 0-255 Red1 0-255 Green1 0-255 Blue1 0-255 White1 0-255 Red2 0-255 Green2 0-255 Blue2 0-255 White2 14 ChD Mode Value Function 0-255 Master Dimmer 0-255 Red1 0-255 Green1 0-255 Blue1 0-255...
  • Page 13 0-63 Linear 64-127 Square 128-191 Invert Square 192-255 S-Curve 15 ChF Mode Value Function 0-255 Master Dimmer 0-255 Fine Master Dimmer 0-255 Red1 0-255 Green1 0-255 Blue1 0-255 White1 0-255 Red2 0-255 Green2 0-255 Blue2 0-255 White2 0-15 Shutter Open 16-255 Strobe From Slow To Fast 0-35...

  • Page 14: Cleaning And Maintenance

    CLEANING AND MAINTENANCE We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use alcohol or solvents! CAUTION! Disconnect from mains before starting maintenance operation. There are no serviceable parts inside the device. Maintenance and service operations are only to be carried out by authorized dealers.
  • Page 15 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
