Tempur-Pedic TEMPUR-Ergo Plus Quick Start Manual

Adjusting Your
TEMPUR-Ergo Plus
™
Adjustable Base
To adjust the Head section, press the HEAD UP
button (1) or HEAD DOWN button (2). Keep pressing
the respective button until the desired height is
reached.
To adjust the Leg section, press the LEG UP button
(3) or LEG DOWN button (4). Keep pressing the
respective button until the desired height is reached.
Press and hold the FLAT button (5) for 3 seconds,
and the bed frame will automatically move into its
complete at position.
1. HEAD UP (HU)
2. HEAD DOWN (HD)
3. LEG UP (LU)
4. LEG DOWN (LD)
6. MEMORY PRESET 1
5. FLAT (F)
7. MEMORY PRESET 2
NOTE: Ensure all obstructions are clear of the
adjustable base's undercarriage when lifting
or lowering the base's head and leg sections
to avoid risk of pinching or damage.
CUSTOMER SERVICE: 1–800–821–6621
Change From a
Single System to a
Tandem System
This function will pair the remotes from two
adjustable bases, allowing each remote to control
both bases in unison.
Pair Remote 1 to Base 2 by pressing and holding the
Learn Button on the Control Box. It will blink three (3)
times when ready.
Press the Learn Button two (2) times. This will select
the second remote channel. The LED will turn off.
Press any button on the new remote. The LED on
the Control Box will blink two (2) times and return on
once programmed.
Pair Remote 2 to Base 1 by repeating the process
above.
NOTE: Each remote must be programmed to
the opposite control box.
CUSTOMER SERVICE: 1–800–821–6621
5
TEMPUR-Ergo
Adjustable Base
Quick Start
Guide
CUSTOMER SERVICE: 1–800–821–6621
Patents Pending
6
© 2013 Tempur-Pedic Management, LLC. All rights reserved.
Plus
™
Rev 101013
