Emfit QS IP-9360 Quick Manual

Package contents
1. Sensor with attached signal conditioner and Wi-Fi module
2. Power supply
3. Plug adapter for European countries
4. Plug adapter for United Kingdom
5. Plug adapter for USA and Canada
6. Plug adapter for Australia
7.
7. This guide
5. 3. 6. 4. 2.
1.
This Quick Guide contains information extracted from the instructions
for use. Please read the "Installation & operating instructions" for the
full instructions for use, including information on safety from:
https://qs.emfit.com/docs
Overview
Sensor
Data signal
EMFIT QS Keep electronic unit
with Wi-Fi transceiver
minimum of 30 cm
distance away from body.
Intended use
The EMFIT QS hardware (Product) and web application (Service) together is a general
wellness product intended to be used for tracking the impact of free-time activities on
recovery, fatigue and sleep quality on a healthy subject. It is not a medical device and is not
intended to be used for diagnosis or monitoring of disease or other conditions, or investiga-
tion of a physiological process.
The product consists of electronic unit with attached bed sensor and a separate power
supply.
Environmental conditions
Storage and transportation Use
• Temperature: 30°C - 50°C • Temperature: 10°C - 40°C
- + + +
• Relative humidity: ≤80% • Relative humidity: ≤75%
• Altitude: <3000 m
Cleaning
CAUTION Do not spray, pour or spill liquid onto the power supply, device, cables, or sensor.
The Emfit device may be surface-cleaned using a soft cloth dampened with either a commercial, nonabrasive cleaner or a
solution of 70% alcohol in water. Lightly wipe the surfaces of the device, power supply, cables and sensor.
Safety instructions
If the device gets wet or starts overheating stop using This product is designed for indoor use only.
immediately and disconnect power
supply from mains power. This product IS NOT intended to be used for direct
diagnosis or monitoring of disease or
Equipment is not suitable for use in the presence of a other conditions, or physiological processes.
flammable anaesthetic mixture with air
or with oxygen or nitrous oxide. Do not use this device for any purpose other than
that specified by the manufacturer.
Only use the power supply (as specified in chapter
Technical specifications) supplied with the product. Do not try to repair the device yourself.
If the instructions are not adhered to, the situation may lead to a death or serious personal injury (in these instructions for use).
ATTENTION - consult accompanying documents (i.e. these instructions for use)
Means that the section contains important information for the user (in these instructions for use).
EMFIT QS New device setup guide A2_v.3.0_28.5.2019.indd 1
A) New device setup
To operate, EMFIT QS needs Internet
connection. It can be either:
A B
Home Wi-Fi or Mobile device as
with Internet access Wi-Fi hotspot
Your Wi-Fi network password Your hotspot Wi-Fi network password
* NOTE! Also for
computing device for setup
Wi-Fi requirements
The 5 GHz Wi-Fi is not supported.
2.4 GHz Wi-Fi is supported.
Wi-Fi channels 1 - 11 are supported. Wi-Fi channels 12 , 13 and 14 are not supported.
This concerns European customers especially.
If you do not know whether your home Wi-Fi is compatible, please see chapter Troubleshooting in
"Installation & operating instructions" (https://qs.emfit.com/docs).
3 4
Connect the power supply to electrical outlet Connect the power cord to Emfit QS.
(110 - 230V AC).
available Wi-Fi networks. Note this especially
using a mobile device as hotspot Wi-Fi
Power cord
Power cord
7 8
A password is requested.
Select and connect to the network:
Emfit_xxxxxx (where xxxxxx is the serial num-
ber of your device).
Windows
Mac OSX
Wi-Fi: On
Networks
Turn Wi-Fi Off
Connections
Emfit_1234567
Network Connected
AppleWiFi
Testwork
Wi-Fi
Emfit_1234567 Join Other Network...
Some-Guest-2.4GHz
Create Network...
2WIRE123 Open Network Preferences...
Ignore possible "No internet connection".
11 12
Select your own Wi-Fi network from the list, Press enter and EMFIT QS will now try to con-
type its password and click enter. nect to your Wi-Fi network. Connecting can
take up to few minutes. You hear short "beep"
If you do not see your wireless network,
sounds and see the red led flashing.
please notice what is said in Step 5.
Emfit
http://192.168.1.3
Detected Wireless Networks
"Your network"
Other Network...
If you still cannot find your Wi-Fi network,
please see chapter Troubleshooting in
"Installation & operating instructions"
(https://qs.emfit.com/docs).
1
To set up the Wi-Fi you need
Select a suitable adapter.
(once):
A computing device*
(computer or tablet or smartphone
with browser)
you need an additional
5
Green and red lights start to flash alternately
and device makes beep sounds.
Upon powering the device will scan all
.
Green Red
Green
Red
Power cord
Sensor cord
If only the red led flashes you need to restore the de-
vice into AP mode. Please see chapter Restoring Emfit
QS device to Access Point (AP) mode in "Installation &
operating instructions" (https://qs.emfit.com/docs).
9
Find the password at the back of the Emfit QS
device (PW: XXX-XXXX-XXX).
Emfit XXX is requesting
WPA2-password
Password:
Show the password
Remember this network
Emfit Ltd, Finland | Product: Emfit QS | Model: IP-9360
Cancel OK
SN: XXXXXX
PIN: XXXXX
PW: XXX-XXXX-XXX
http://192.168.1.3
Contains FCC ID: W70MRF24WG0MAMB
Contains transmitter module IC:
7693A-24WG0MAMB
Designed and manufactured in Finland.
Note! The password must be filled in with the
hyphens.
13
Unsuccessful connection
Device will make low tone sounds. Red and
green lights flash alternately again. This means
device has returned to state it was in step 6
(Access Point mode). Please try again starting
from step 6 and make sure you typed your own
Wi-Fi network password correctly.*
Red light starts flashing. Red and green lights are flashing alternately.
*Still cannot connect? Please see chapter
Troubleshooting in "Installation & operating
instructions" (https://qs.emfit.com/docs).
2
Connect the correct adapter.
Ensure that it locks in its place.
6
With your computing device scan for wireless
networks.
...
Green Red Green Red
SCANNING
Green
Red
Sensor cord
Computing device
10
Open your computing device's browser
(Mozilla, Safari, Chrome, Internet Explorer etc.).
Type in address/url bar:
http://192.168.1.3 and press enter.
http://192.168.1.3
Note! Make sure address starts with http
and not https!
If you cannot access above IP-address,
please see chapter Troubleshooting in
"Installation & operating instructions"
(https://qs.emfit.com/docs).
14
Successful connection
Device will make high tone sounds. This means
that the password you typed is correct. To ver-
ify succesful connection, ensure the sensor is
not sensing any vibration and is preferably un-
der the mattress; see section C 22–25.
In about 1-3 minutes either green light will start
flashing, or red light alone will keep flashing. If the
later, please contact Emfit support:
Email: qs@emfit.com
Phone: USA (512) 266-6950, EU +358 20 778 0870
CLICK!
