Performing a Functional Check
80A03 TekConnect Probe Interface Module Instruction Manual
To verify that the 80A03 TekConnect Probe Interface Module is functioning
properly, perform the following procedure.
Refer to Table 2 for a list of recommended equipment.

Table 2: Recommended equipment for performing a functional check

Item description
Sampling oscilloscope
Sampling module
TekConnect probe
Probe tip adapter
Semi-rigid SMA cables (2)
SMA cable
50 Ω termination, SMA-type
Torque wrench
To verify the functionality of Channel A, perform the following tasks:
1. Initialize the system:
a. Power on the sampling oscilloscope.
b. Wait for the boot up process to complete.
c. Press the front panel Default Setup button.
2. Connect the signal source:
a. On the sampling oscilloscope, connect the SMA cable to the Internal
Clock Output. See Figure 7 on page 10 for details.
b. Connect the Probe Tip Adapter with 50 Ω termination to the other end of
the SMA cable.
3. Set up the trigger system:
a. In the UI application toolbar, select Internal Clock from the Trig List
menu box.
Recommended example
Tektronix CSA8000 or TDS8000
Tektronix 80E02, 80E03, or 80E04
Tektronix P7000 Series
Tektronix P7225, P7240: 015-0678-xx
Tektronix P7260: 067-1456-xx
Tektronix P7330, P7350: 067-0419-00
Tektronix part number 174-4857-xx
Tektronix part number 174-1427-00
Tektronix part number 015-1022-xx
SMA 5/16, 8 in-lb
Getting Started
9
