It's Time to Get Real.
Completely Characterize
Multiple correlated views
in all domains (Frequency, Time,
Amplitude, Phase, Modulation)
with intuitive user interface.
®
Revolutionary DPX spectrum
processing for unmatched
troubleshooting and live transient
analysis.
Touch screen, mouse and front
panel controls directly adjust settings
in the views.
Windows XP Operating System
®
with Tek OpenChoice for easy file
operations, printing, Ethernet and
GPIB control, remote connections
and more.
Two external triggers to capture
key event information (1 front, 1 rear).
4
www.tektronix.com/rsa
Time-varying RF Signals
Two frequency ranges:
9 kHz to 6.2 GHz (RSA6106A) or
9 kHz to 14 GHz (RSA6114A).
DVD ±RW (standard) for waveform
storage. Removable HDD (optional)
for data security.
Familiar spectrum analyzer
controls plus fast access to all
acquisition and measurement
settings.
USB connections (2 front, 2 rear),
for mouse, keyboard and memory.
DC-Protected Input
±40 V DC, over entire frequency
range, +30 dBm CW, 75W Pulse
Maximum.
