  • Page 1 It’s Time To Get Real. Your Guide to Selecting the Right Real-Time Spectrum Analyzer...
  • Page 2 RF signals produced by the device under test. By providing insight into how parameters change over continuous time, the Real-Time Spectrum Analyzer adds another crucial dimension to all of these measurements. Select Your Real-Time Spectrum Analyzer Performance...
  • Page 3 9 kHz to 6.2 GHz (RSA6106A) or 9 kHz to 14 GHz (RSA6114A). DVD ±RW (standard) for waveform storage. Removable HDD (optional) for data security. Familiar spectrum analyzer controls plus fast access to all acquisition and measurement settings. USB connections (2 front, 2 rear), for mouse, keyboard and memory.
  • Page 4 Tektronix’ patented Digital Phosphor technology, standard in our RSA6100A Series Real-Time Spectrum Analyzers, reveals signal details that are completely missed by conventional spectrum analyzers and vector signal analyzers.
  • Page 5 These advanced triggers provide the ability to capture a seamless record of RF signals into memory and perform time-correlated, multi-domain analysis. Unlike traditional swept spectrum analyzers, the Real-Time Spectrum Analyzer offers a Power Trigger with user-settable span, enabling spectrum capture whenever the power of any signal crosses a user-defined threshold.
  • Page 6 RF signal activity and thoroughly analyze its unique behavior – over time, in multiple domains – is becoming increasingly essential. Tektronix’ Real-Time Spectrum Analyzers meet these requirements by seamlessly capturing and recording all the signals across a user-selected span – up to 110 MHz, depending upon model used.
  • Page 7 Analyze Complex RF Signals The analysis capabilities of the Real-Time Spectrum Analyzer provide simultaneous time-correlated views of a signal in the frequency, time and modulation domains, enabling much faster resolution of complex problems that often occur in today’s RF systems.
  • Page 8 Differential Analog IQ Input Pulsed RF Analysis Advanced Analysis Pulsed Signal Suite AM/AM, AM/PM, 1 dB Compression Cellular Standards Analysis 802.11a/b/g/n Analysis RFID Analysis WiMAX Analysis www.tektronix.com/rsa Solutions for Your Digital RF Challenges Applications Spectrum Radar & Pulsed SDR and Management...
  • Page 9 Please visit www.tektronix.com Copyright © 2007, Tektronix. All rights reserved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication super- sedes that in all previously published material. Specification and price change privileges reserved.
