4MOMS RockaRoo Quick Start Manual

Assembly
1.
Insert the front of the central rail into the
grooves in the front of the rocking trolley.
Then push the rail down until you hear a click.
4.
Pull the seat fabric over the toy bar opening
and snap into place.
7.
Place toy balls into the toy ball ring.
10.
Turn on rockaRoo
by pressing the
power button.
rockaRoo
2.
Lock the lever on the back
of the rocking trolley.
5.
Pull the bottom of the seat fabric
down and snap into place.
90°
8.
Install the toy bar by inserting the bar
to the side and turning 90 degrees
so it is facing forward.
11.
Select rocking speed
by turning the knob.
™
3.
Insert seat ring into the center support rail until you
hear it click at both the top and bottom.
6.
Pull child restraint harness through back of
the seat fabric.
9.
Once assembled, plug into power supply.
