Meaning of the TRANSCEIVER LEDs:

LED number Colour
LED OP2 green
LED OP3 red
LED OP4 green
LED OP5 green

Meaning of the INDICATION LEDs:

LED number Colour
LED OP8 green
LED OP6 green
LED OP7 green

Meaning of the STATUS LEDs:

LED number Colour
LED OP1 green
LED OP9 red
PSTN-2-IP & PSTN-2-IP GPRS Quick reference
Description
Flashes slowly when the firmware in the transceiver functions correctly.
Illuminates when a message is in the buffer or when no dialers have
been programmed.
nd
Status of the 2 transceiver with corresponding backup path.
st
Status van de 1 transceiver with corresponding backup path.
Description
Power supply present
LAN activity
LAN link
Description
Watchdog LED. Should be constantly illuminated to indicate that the
hardware functions correctly. Is turned off during flashing.
Is illuminated when the priority relay is activated. The incoming PSTN
line (CMK) is connected to the outgoing PSTN telephone line (TEL). As
long as this led is illuminated the AlphaCom PSTN-2-IP (GPRS) will not
transmit alarm messages received via the PSTN line (CMK).
