TOUCH DYNAMIC INC.
EC150 monitor wall mount
installation
10/15/2012
Proprietary Note: The information contained in this document is confidential and proprietary to Touch Dynamic (TD) Inc. The document or the
information it contains is NOT to be used, reproduced, modified or disclosed outside of Touch Dynamic Inc. without the written permission of
Touch Dynamic Inc.
Advertisement
Table of Contents
Related Manuals for Touch Dynamic EC150
Summary of Contents for Touch Dynamic EC150
- Page 1 Proprietary Note: The information contained in this document is confidential and proprietary to Touch Dynamic (TD) Inc. The document or the information it contains is NOT to be used, reproduced, modified or disclosed outside of Touch Dynamic Inc. without the written permission of...
-
Page 2: Package Contents
Package contents Universal Mounting Wall plate Monitor plate Hardware kit... -
Page 3: Installation Instructions
Installation Instructions 1) Disconnect all the cables from the monitor I/O ports and remove the power supply. Place the monitor on the flat secure surface 2) Remove 2 screws that secure the stand and remove the stand Remove 2 screws 3) Remove 2 screws from the hinge cover Remove 2 screws... - Page 4 4) Use the flat screw driver to pull the cover up and remove it Insert the flat screwdriver in the opening and pull it up to unclip the hinge cover. 5) Remove 4 screws from the hinge plate.
- Page 5 6) Put the monitor plate (the hooks should face down) and secure it with 4 screws Secure the plate with 4 screws Install the wall mount bracket at the desired location on the wall and put the system on. All 4 hooks must be engaged to ensure the correct mounting.
