EC150 Monitor Manual V1.1 Warning! It will cause malfunction if the monitor is operating with unspecified power supply unit or incorrect power voltage. Do not exposure this unit in the rain or moisture environment to reduce the risk of fire or electric shock.
EC150 Monitor Manual V1.1 I. FCC Warning Statement WARNING Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
EC150 Monitor Manual V1.1 II. Introduction Touch Dynamic’s EC150 is color TFT LCD monitor, integrate with resistive touch, suitable for many types of applications. Features Optimal display resolution 1024 * 768 VESA 75 * 75 mm wall mount standard...
EC150 Monitor Manual V1.1 Unpacking the monitor Put the monitor on a clean surface, make sure the box in upright position. Remove packing materials from inside of box. Check accessory Please make sure all the accessory are included: Standard Items a.
EC150 Monitor Manual V1.1 III. Installation I/O placement 1 DC JACK 2 DVI 3 VGA 4 USB B Type 5 Dual USB A Type 6 RS232 7 RJ45 (+12V for VFD ONLY ) Warning :Please do not plug non-powered peripheral devices(e.g. printers, scanners etc)into the powered COM ports- as you can permanently damage your...
EC150 Monitor Manual V1.1 To PC 1. Connect VGA cable from monitor to PC 2. Connect USB touch cable to PC (Connect to the Serial port if you have serial interface touch) 3. Connect DC plug to monitor and the other side to wall outlet...
EC150 Monitor Manual V1.1 Touch Driver installation Please download the driver from Touch Dynamic's website 1. Double click “setup.exe” from driver menu 2. Click “next” from welcome window 3. Click “next” from choose destination location window 4. Click “next” from ready to install the program 5.
Page 9
EC150 Monitor Manual V1.1 Calibration procedures: Double click “POS Touch+” icon to run calibration function Follow 9 points linearity calibration procedures and save the data Follow free draw calibration Exit calibration menu Reboot PC...
EC150 Monitor Manual V1.1 Customers Display (optional) Components of Customers Display Kit: Customers Display Screw 1. Remove the screws (x3). 2. Open the Hinge Cover and I/O Cover 3. Connect the Customers Display cable to the COM port of the monitor.
Page 13
EC150 Monitor Manual V1.1 5. Fasten the screws (x2) to fix the Customers Display bracket to the Hinge bracket. 6. Fix the Stand by fasten the screws (x2).
EC150 Monitor Manual V1.1 Control Buttons a.) Pressing to execute AUTO-Adjusting function. This function will set the monitor display area to the optimal position. Auto Adjusting b.) Sometimes this function can't achieve the optimal effects. Please follow the manual adjusting procedure.
EC150 Monitor Manual V1.1 Structure of OSD settings Third First Level Second Level Operating Procedure Level Press “UP” or “DOWN” to adjust H-phase & Auto Adjust H-position & V-position clock automatically. Press “UP” key to increase brightness, “DOWN” Brightness key to decrease brightness.
EC150 Monitor Manual V1.1 IV. For your safety When move the monitor, always switch off power and disconnect all cables to avoid any danger. Please use the power and signal cables correctly when install or bend it. In case of notice any abnormal smell or noise, please stop operation and call the nearest dealer or service center.
EC150 Monitor Manual V1.1 VII. Product General Specification Model EC150 Cabinet color Black Display size 15.0" Active Area 304 * 228 mm Optimal Resolution 1024 * 768 Color Arrangement RGB-stripe Brightness 250 cd/m² (typ) Contrast Ratio 600:1 Response Time 8 ms (typ)
