  • Page 2 User Manual Revision v1.3 May 2011 Breeze Touch Monitor...
  • Page 3 Copyright May 2011 All Rights Reserved Manual Version 1.3 Part Number: 3LMPP1500113 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 4: Important Safety Instructions

    Safety IMPORTANT SAFETY INSTRUCTIONS To disconnect the machine from the electrical power supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine.
  • Page 5 CAUTION ON LITHIUM BATTERIES There is a danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components.

  • Page 6: Revision History

    Revision History Revision Description Revision Date Number  Initial release 2008 September B13 MB upgraded  2009 February  MSR with finger print module added 17” system spec added 2010 January   B16 MB added 2011 May...

  • Page 7: Table Of Contents

    Wall mount kit Installation for Panel display .............15 System Disassembly ....................16 Removing the Stand..................16 Replacing the Adapter..................16 Specification .......................17 B13 Scalar board .....................18 B16 Motherboard .....................24 Appendix A: Drivers Installation ..................29 Appendix B: OSD Functions for B13 Board ...............30 Appendix C: OSD Functions for B16 Board ...............33...

  • Page 8: Item Checklist

    1. Item Checklist Take the system unit out of the carton. Remove the unit from the carton by holding it by the foam inserts. The following contents should be found in the carton: Standard Items a. COM cable (optional) b. VGA cable c.

  • Page 9: Optional Items

    Optional Items a. MSR module b. MSR + Finger printer module c. VFD module d. Wall-mount kit module...

  • Page 10: System View

    2. System View Front View Rear View Stand...

  • Page 11: I/O View

    I/O View I/O View for B13 PS/2 RJ45-COM Power button USB to PC PS/2 to PC COM to PC DC - IN I/O View for B16 RJ45-COM Power Auto tune USB to PC DC-IN COM to PC...

  • Page 12: System Installation

    3. System Installation Stand Holder Installation a. Slide the stand bracket into the position b. Fix the VESA and stand with the screws (6 total, 3 on each side). c. Use rubber caps on both side openings d. Align larger end of the teardrop mounting holes on the VESA hinge bracket with fixing screws (x4) on the rear cover of the system.

  • Page 13: Vfd Installation

    VFD Installation a. Slide the VFD module to the system VESA bracket and tighten it with the thumb screw. b. Connect the VFD cable to the COM port and the VFD module...

  • Page 14: Msr Installation

    MSR Installation a. Loosen the screws (2) on the MSR dummy cover b. Fasten the grounding cable with screw (1) and connect the MSR cables to the respective connectors on the system. c. Connect the MSR module to the system and tighten the screws (3)

  • Page 15: 2-In-1 Msr+Fingerprint Module Installation

    2-in-1 MSR+Fingerprint Module Installation Please first follow Chapter 4.3 /a, and go next to below steps of Chapter 4.4. a. Connect 2-in-1 MSR + Fingerprint b. Tighten the screws (3) as the circles cable and slide the module into the marked position c.

  • Page 16: Power Cord Installation

    Power Cord Installation The Power adapter is installed in the metal bracket fixed in the stand base. Connect the Power cord to the power adapter.

  • Page 17: Wall Mount Kit Installation For Panel Display

    Wall mount kit Installation for Panel display If you want to mount the POS monitor on the wall, please order the wall mount kit from your distributors and follow the steps below to install the wall mount display unit.  Wall-mount kit accessory: d.

  • Page 18: System Disassembly

    4. System Disassembly Removing the Stand a. Loosen the thumb screw. b. Slide the system upward to separate from the stand. Replacing the Adapter a. Route the adapter cable from the hole of cable management of the stand. b. Disconnect the power cord from the adapter. c.

  • Page 19: Specification

    5. Specification Model Name Breeze Touch Main board LCD Panel Panel Size 15" / 17” Brightness 15”: 250nits / 17”: 300 nits Resolution 15”: 1024 x 768 / 17”: 1280 x 1024 Touch 15”: Resistive / 17”: Resistive /SAW External I/O Ports 2 ( 1 x IN to PC, 1 x OUT to MSR / PS/2 Keyboard )

  • Page 20: B13 Scalar Board

    B13 Scalar board 5.1.1 B13 Scalar board layout JP11 JP12 JP10 B13 V1.1...
  • Page 21 5.1.2 Connectors & Functions Connector Function LCD Interface Connector Inverter Connector Power State LED Connector Internal USB Device Connector (Down-Stream) CN10 Internal COM Device Connector (Output) CN11 Keypad Connector CN12 Card Reader Connector CN14 Internal +12V Connector CN15 Internal USB Device Connector CN16 ELO Touch COM1...

  • Page 22: Jumper Settings

    5.1.3 Jumper Settings 1. Power Mode Setting Function / Location (1-2) ▲On Power Mode On: The monitor powers on as soon as it is connected to power. Power Mode Off: The monitor has to be switched on with the power button. 2.
  • Page 23 3. USB Touch Setting Function / Location JP10 (1-3) (2-4) (3-5) (4-6) ▲On Board USB touch Internal USB Connector 4. CN10 COM Power Setting Function / Location JP11 (1-2) (3-4) JP11 ▲COM+5V COM+12V JP10 5. LCD ID Setting Panel LVDS Support Panel Resolution Size...
  • Page 24 JP12 6. COM Port for RS232 Touch / Internal COM / External COM Setting Function / (1-2) (3-4) (5-6) (1-2) (3-4) (5-6) (1-2) (3-4) (1-2) (3-4) Location (7-8) (9-11) (11-12) (7-8) (9-10) (11-12) (5-6) (7-8) (5-6) (7-8) RS232 Touch Int./ Ext. 7.

  • Page 25: Connectors Pin Definition

    5.1.4 Connectors Pin Definition CN4: Power State LED Connector Pin 1 LED_On Pin 2 Pin 3 LED_Off CN10: Internal COM Device Connector (Output) Pin 1 RS232_DCD# Pin 2 RS232_RX# Pin 3 RS232_TX# Pin 4 RS232_DTR# Pin 5 Pin 6 RS232_1_DSR# Pin 7 RS232_RTS# Pin 8...

  • Page 26: B16 Motherboard

    B16 Motherboard 5.2.1 B16 Motherboard layout B16 V1.0...
  • Page 27 5.2.2 Connectors & Functions Connector Function USB Audio USB Port (Down-Stream) Inverter Connector Keypad Connector LVDS Connector CN10 PS/2 Input Connector CN11 E-Turbo Touch Panel Connector CN14 ELO Touch CN15 OSD On/Off LED CN16 COM Port Connector (Output) PRW1 Power Adapter RJ45-1 COM Port Connector (Output) COM1...
  • Page 28 5.2.3 Jumper Settings 1. Touch Interface Setting Function JP6 (1-2,3-4,5-6,7-8) JP8 (1-2,3-4,5-6,7-8) RS232 ▲USB 2. Touch Setting Function JP11 (1-2,3-4,5-6) ▲EXTERNAL INTERNAL JP11 3. COM Power Setting Function JP10 (1-2,3-4,5-6) ▲COM RI JP10 COM+5V COM+12V ▲ = Default...
  • Page 29 4. LCD ID Setting Panel LVDS Support Panel Resolution Size Bits Channel (1-2,3-4,5-6,7-8) ▲ 1024 x 768 Single 6PN115052D02 15” 1024 x 768 Single 15” 6PN115052D01 6PN117062320 17” 1280 x 1024 Dual 6PN117062130 ▲ = Default 5. MSR Power Setting Function (1-2,3-4) ▲PS2...
  • Page 30 6. USB Channel Setting PORT2 Function / Location (1-2, 3-4, 5-6, 7-8) USB (CN4) ▲USB to Audio PORT4 Function / Location (1-2, 3-4, 5-6, 7-8) ▲MSR USB (CN2) ▲ = Default...

  • Page 31: Appendix A: Drivers Installation

    Appendix A: Drivers Installation The shipping package includes a Driver CD. You can find every individual driver and utility that enables you to install the drivers in the Driver CD. Please insert the Driver CD into the drive and double click on the “index.htm” to pick up the models.

  • Page 32: Appendix B: Osd Functions For B13 Board

    Appendix B: OSD Functions for B13 Board Condition Normal Mode Power No Function No Function No Function Menu (Signal Input Mode) Exit Menu Menu Mode Power Select/Confirm Left Right Mode...
  • Page 33 In the signal input mode, pressing the SW5 key to enter Menu Mode. Press the SW3 or SW4 key to select video icon then press the SW2 key to enter brightness adjustment.
  • Page 34 Press the SW3 or SW4 key to adjust brightness value. Menu mode window will automatically close when there is no command for 10 seconds.

  • Page 35: Appendix C: Osd Functions For B16 Board

    Appendix C: OSD Functions for B16 Board Condition SW1+SW2 Normal Mode Menu Mode Power Auto Tune (Signal Input Mode) (SW1 + SW2 keep press 3 seconds) Menu Mode Right Select No Function PS: 2 Key OSD only shifts to right when press SW1 key in menu mode. (Ex: Brightness Value: 1→10→1)
  • Page 36 In the signal input mode, keep pressing the SW1 + SW2 key 3 seconds at the same time. In Press the SW1 key to select video icon then press the SW2 key to enter brightness adjustment.
  • Page 37 Press the SW1 key to adjust brightness value.(Brightness value: 1→2→3→4……..10 →1→2…..) Menu mode window will automatically close when there is no command for 10 seconds..
