Summary of Contents for Hills Folding Frame Clothesline Series
- Page 1 Post Kit Folding Frame Clothesline Product Manual...
- Page 2 Introduction Congratulations Congratulations on the purchase of your new Hills Folding Frame Clothesline Post Kit. It is important that you read this Product Manual thoroughly before installation and use. In this way you will benefit from all the design features and enjoy safe use of the product.
- Page 3 Installation Step 2 – Select a suitable location Carton contents 2.1 Select a suitable location for your Post Part name Qty. mounted Folding Frame Clothesline. Post - fixed 2.1 Ensure you have left su cient space Cross brace surrounding the Clothesline (Fig. 1). Product manual We recommend 0.1m each side and 0.75m in front.
- Page 4 Installation Step 3 – Installing the Post Kit Post Hole Centres 3.1 You will require the following materials Product Centres and tools: (mm) Pre-mix concrete Double Folding Frame Clothesline 2200 Coarse gravel Single Folding Frame Clothesline 2200 Spade Compact Folding Frame Clothesline 2200 Tape measure Spirit level...
- Page 5 Installation Step 4 – Installing Fixed Posts 4.1 Having selected a suitable location, dig two holes approximately 200mm diameter x 600mm deep at hole centres to suit your product (see Post Hole Centre Chart on pg. 4). Place approximately 150mm of coarse gravel into the hole.
- Page 6 Warranty 10-Year Warranty* *In addition to other rights and remedies that may be available under any applicable law, AMES Australasia Pty Ltd warrants to the purchaser of the product (customer) that this Post Kit will be free from defects in workmanship and materials for 10 years from the date of purchase of the product. If a defect in material or workmanship becomes evident during that period, AMES Australasia Pty Ltd will, at its option, either: •...
- Page 7 Customer Service Centre during their local business hours: Australia 1300 300 564 New Zealand 0800 021 027 Email hhl.enquiries@amesau.com Hills Websites hillshome.com.au Hills Home Living hillshome.com.au/need-help/ Hills Consumer Advice...
- Page 8 AMES Australasia Pty Ltd A.B.N. 89 169 427 061 Issue Mar 2019 HD10682c...
