- Page 1 NVR SERIES NVR Series DG-SR4508 8-Channel Network Video Recorder V2.0 V2.0 2018-02-14 2017-12-14...
- Page 2 Please check with your local distributors for latest information. No part of this document can be copied or reproduced in any form without written consent from the company. Trademark DIGISOL is a trademark of Digisol Systems Ltd. All other trademarks are the property of the respective manufacturers.
-
Page 3: Package Contents
Product Overview Thank you for purchasing DIGISOL Network Video Recorder! This QIG is a reference guide for the installation and operation of your NVR. Before installation and operation please read the safeguards and warnings mentioned in the sections below carefully. -
Page 4: System Requirements
System Requirements The following system requirements are recommended: Windows XP, Vista or Win 7 operating system (both 32 or 64 bits version) 4GB of system memory 2GB of Display card memory 100GB of available hard disk space on system drive ... -
Page 5: Hdd Installation
Hardware Installation Inspect the NVR Packaging and Check Contents Upon receiving your NVR, please check for any visible damage to the external packaging. If the external packaging is damaged, please document the damage and report to the shipping agent. The protective materials used in packaging of the NVR can protect against most accidental damage during shipping and should be saved. - Page 7 Rear Panel Power on NVR After installing the hard drive, connect HDMI/ VGA cable and mouse on the NVR & Power ON the NVR. Enter the system and intelligent deployment will run automatically like below:...
- Page 8 Once the intelligent deployment step is completed, it will prompt a start wizard as shown below:...
- Page 9 Live View Interface Menu The following are the description of icons displayed on Live View of NVR. Click this icon to enter the Main Menu. Indicates that NVR interface is unlocked. Indicates Alarm Status. Display Network Status & IP Address. Fast Multi-Channel Playback.
- Page 10 If you left click on video channel, it will display a mini menu of channel. Digital Zoom Video Parameters Turn ON/ Off Manual Record Playback the respective Channel Channel Information Microphone icon for supported IP camera.
- Page 11 Playback You can view the recordings by clicking Search option based on Time/ Date as shown below:...
- Page 12 Mobile App Viewing 1. Installation of Mobile App “Realview Pro” is available to download for Android & Apple iOS. You can scan the App QR Code displayed under “Cloud Service Menu” or Click icon on the bottom tool bar of NVR display interface. “QR Code Reader” is required to scan the App code.
-
Page 13: App Interface
2. App Interface Open the App, it will display the following screen as shown in Fig1. Click on Add Device & scan the NVR QR Code as displayed on NVR Video display under Cloud Service option. Fig1 Fig2... - Page 14 Once it detects device, it will display message as “Success”, as per screen Fig3. Fig3 Fig4 You can view the live Video as displayed in screen Fig4 shown above. You can also auto search the IP camera under LAN tab as shown in Fig5 below: Fig5...
- Page 15 You can playback the recordings of NVR using the app as shown below:- Fig6 This product comes with Two Years warranty. For further details about warranty policy and Product Registration, please visit support section of www.digisol.com...
- Page 16 DIGISOL SYSTEMS LIMITED L-7 Verna Industrial Estate Salcete GOA-403722 Email: helpdesk@digisol.com A Subsidiary of Smartlink Network Systems Ltd. www.digisol.com...
