Troubleshooting
All CommandStik Products are thoroughly tested prior to shipment. However, should you encounter a problem during
installation or during the life of the product, follow the guide below for information on repair and troubleshooting. Additional
information may be obtained from the factory technical help line at 314-996-2800. Follow the guide below for information on
repair and troubleshooting.
PROBLEM
MR6MC Light
Head Module
not operating
when powered.
Reference Number
1
2
3
4
5
6
7
8
9
10
11
920-0546-00 Rev. A
TROUBLESHOOTING GUIDE
QUESTIONS
A. Bad power/ground Connection
N/A
B. Defective module.
9
5
10
Part Description
Outer Panel
Chassis
AS-10 Universal Mounting Bracket
MR6MC Module
.625 Diameter Cap
Circuit Board Assembly
Internal tooth starwasher .250
1/4-20 x 3/8" Phil Pan Hd, Black Zinc, Stl
.750 Diameter Cap
Dedicated Mtg Bkt 2011+ Dodge Charger
#6-32 X 3/4" Lg Phil Pan Head Screw SS
POSSIBLE CAUSE
Parts List
4
11
6
5
*Contact Code 3, Inc for P/N
SOLUTION
A. Fix connection.
B. Replace module
1
2
Part Number
T15552
220-0906-00
S50008
T05431
160-0494-00
T06935
T89965
T00232
220-0859-00
T57024
3
7
8
Qty
1
2
2
Up to 6
2
1
4
4
2
2
4
Page 7 of 8
