LumaWarm Top Mount Installation
Top Mount Installation
Bolt holes only accessible
through top-side access
Some toilet fixtures have top-side access only. If you cannot access
the bolt holes and screws from underneath your toilet fixture, you will
need to use the LumaWarm Top Mount Mounting Hardware.
Kit Includes: 2 mounting blocks, 2 Phillips screws
(Visit brondell.com or call us at 888-542-3355 to purchase)
Insert the Phillips screws
the holes in the mounting blocks
as shown.
You may also use the screws
from your original toilet seat.
through
Use a Phillips screwdriver to
into your toilet fixture bolt holes
sure the mounting blocks are positioned vertically.
Standard Installation
Bolt holes accessible above
and below porcelain
fasten the screws
until snug. Make
Page 1
Advertisement
Table of Contents
Related Manuals for brondell LumaWarm
Summary of Contents for brondell LumaWarm
- Page 1 Some toilet fixtures have top-side access only. If you cannot access the bolt holes and screws from underneath your toilet fixture, you will need to use the LumaWarm Top Mount Mounting Hardware. Kit Includes: 2 mounting blocks, 2 Phillips screws (Visit brondell.com or call us at 888-542-3355 to purchase)
- Page 2 LumaWarm Top Mount Installation cont’d. Moisten the three pads underneath the Slide the LumaWarm seat onto the LumaWarm seat for a more secure fit. mounting blocks, being careful to line up the LumaWarm’s mounting track with the mounting blocks. Page 2...
