5

Electrical and radio characteristics

5.1 Absolute Maximum ratings

Absolute maximum ratings for supply voltage and voltages on digital and
analog pins of the module are listed below. Exceeding these values will
cause permanent damage.
Peak current of power supply
Voltage at digital pins
Voltage at POWER pin

5.2 Operating temperatures

Operating temperature

5.3 Power Consumption

The current drain from the Vcc power input line is dependent on various
factors. The three most significant factors are the voltage level at Vcc,
UART baud rate and the operating mode.
The hardware specification for the blu
range of 3.6 to 6.0v at Vcc. Tests have shown that there is no significant
difference in current draw when Vcc is 5 or 6V. Therefore the data
presented below, pertains to Vcc levels of 3.6 and 5v only. Tests have
shown that where power drain is an issue, it is best to keep Vcc at the
lower end of the range.
The UART baud rate has a bearing on power drain because as is normal
for digital electronics, the power requirements increase linearly with
increasing clocking frequencies. Hence higher baud rates result in a
higher current drain.
Finally with regards to operating mode the significant modes are; idle,
waiting for a connection, inquiring, initiating a connection and connected.
With connected mode, it is also relevant to differentiate between no data
Minimum
0mA
-0.3V
3.3V
Minimum Typical
-20°C 25°C
2i
module allows for a voltage
16 of 36
Maximum
100mA
3.7V
7V
Maximum
+75°C
