TDK TFS Series TFSB10052450-1003A1 Specifications

Thin-Film Band Pass Filters
For Bluetooth & 2.4GHz W-LAN
TFS Series TFSB10052450-1003A1

SHAPES AND DIMENSIONS

Top view
1
2 4
3
0.5±0.1
0.3±0.1
Dimensions in mm

RECOMMENDED PC BOARD PATTERNS

0.3
0.7
1.6
Line width be designed to mach 50Ω
characteristic impedance depending
on PCB material and thickness

ELECTRICAL CHARACTERISTICS

Item
Insertion loss [2400 to 2500MHz]
Return loss [2400 to 2500MHz]
[1900MHz]
Attenuation [4800MHz]
[7200MHz]
Operating
Temperature range
Storage
• Ta:+25°C
•
Conformity to RoHS Directive: This means that, in conformity with EU Directive 2002/95/EC, lead, cadmium, mercury, hexavalent chromium, and
specific bromine-based flame retardants, PBB and PBDE, have not been used, except for exempted applications.
• All specifications are subject to change without notice.
Bottom view
0.1±0.1
Terminal functions
1 IN
2 GND
3 OUT
4 GND
ø0.3 Through-hole
Land pattern
Solder resist
No pattern resist
Dimensions in mm
(dB)
(dB)
(dB)
(dB)
(dB)
(°C)
(°C)
Minimum value Typical value
— 2.8
9 14.0
30 43.1
30 49.7
22 48.5
–40 —
–40 —
001-02 / 20090224 / e721_tfsb10052450_1003a1.fm
(1/2)
Conformity to RoHS Directive
Maximum value
3.5
—
—
—
—
+85
+85
