Memorex MIHTS3202 Operation User's Manual

Front sound speaker system
Hide thumbs Also See for MIHTS3202:

Advertisement

SAFETY PRECAUTIONS

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
FCC WARNING:
This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless
the modifications are expressly approved in the instruction manual. The
user could lose the authority to operate this equipment if an unauthorized
change or modification is made.
ATTENTION:
POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA
PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE
LA PRISES ET POUSSER JUSQU'AU FOND.
iPod is a trademark of Apple Computer, Inc., registered in the U.S. and
other countries.
All manuals and user guides at all-guides.com
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE:
The lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
ATTENTION:
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
1

Advertisement

Table of Contents
loading

Summary of Contents for Memorex MIHTS3202

  • Page 1: Safety Precautions

    SAFETY PRECAUTIONS All manuals and user guides at all-guides.com CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the...
  • Page 2: Surge Protectors

    SAFETY PRECAUTIONS All manuals and user guides at all-guides.com INFORMATION: This equipment complies with Class B digital device regulations. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 3 SAFETY PRECAUTIONS All manuals and user guides at all-guides.com Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit. For example, this unit may not have the capability to be connected to an outdoor antenna.
  • Page 4 SAFETY PRECAUTIONS All manuals and user guides at all-guides.com consult your appliance dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions. 11. GROUNDING OR POLARIZATION This product is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other).
  • Page 5: Replacement Parts

    SAFETY PRECAUTIONS All manuals and user guides at all-guides.com protection against voltage surges and built-up static charges. Section 810 of the National Electric Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge product, size of grounding conductors, location of antenna discharge product, connection to grounding electrodes and requirements for grounding electrodes.
  • Page 6: Location Of Controls

    LOCATION OF CONTROLS All manuals and user guides at all-guides.com FRONT 1. iPod Dock 2. Standby Indicator 3. Display 4. Remote Sensor RIGHT SIDE 1. STANDBY/ON Button 2. FUNCTION Button 3. PLAY/PAUSE Button 4. VOLUME + Button 5. VOLUME – Button...
  • Page 7 LOCATION OF CONTROLS All manuals and user guides at all-guides.com REAR 1. DVD Audio Right and Left In Jacks 2. TV Audio Right and Left Audio In Jacks 3. S-Video OUT Jack 4. Video Out Jack 5. Wall Mount Hooks (WALL MOUNT ASSEMBLY PART NO.
  • Page 8 LOCATION OF CONTROLS (CONTINUED) All manuals and user guides at all-guides.com REMOTE 1. STANDBY/ON button 2. MUTE button 3. MODE button 4. Skip/Search o Button (iPod) 5. MENU button (iPod) 6. SELECT button (iPod) 7. BASS – button 8. VOLUME – button 9.
  • Page 9: Power Source

    POWER SOURCE All manuals and user guides at all-guides.com Insert the AC plug (with the 2 blades) into a conveniently located AC outlet having 120V, 60Hz. NOTE: The AC plug supplied with the unit is polarized to help minimize the possibility of electric shock. If the AC plug does not fit into a AC Outlet nonpolarized AC outlet, do not file or...
  • Page 10: Wall Mounting

    WALL MOUNTING All manuals and user guides at all-guides.com Hole Plastic Na ils 200MM WAL L WAL L Measure for the holes in the wall as shown, and then drill holes using an 8mm drill bit. If Use a hammer and gently nail in the four anchors, if a stud is not directly behind the hole.
  • Page 11: Output Connections

    OUTPUT CONNECTIONS All manuals and user guides at all-guides.com If you are using an iPod that has photo/video capability, and your TV has a standard video or an S-Video input, you can connect the unit to the external TV with the Audio cable (not included) or an S-Video cable (not included).
  • Page 12: Input Connections

    INPUT CONNECTIONS All manuals and user guides at all-guides.com Connect a DVD to the DVD Audio In jacks and a TV to the TV Audio In jacks to output the sound through this speaker. DVD: To listen to the DVD player connected to the DVD In jacks, press the FUNCTION button until DVD appears in the display.
  • Page 13: Sound Settings

    SOUND SETTINGS All manuals and user guides at all-guides.com VOLUME Repeatedly press the MODE Press the VOLUME – button 1 to button to cycle through the decrease or the VOLUME + EQ/Bass settings (BYPASS, SRS- button 2 to increase the volume. WOW, TSXT and TSXT-DC) to The volume level will appear pick the desired sound preference.
  • Page 14: Inserting An Ipod

    INSERTING AN IPOD All manuals and user guides at all-guides.com Rotate the iPod compartment as Slide the iPod into the Universal shown. Insert the Universal Dock Dock (as shown). Gently push included with your iPod (A) into down so the connector on the the iPod compartment (B) (as iPod slides onto the connector on shown), making sure the tabs are...
  • Page 15: Operation

    OPERATION All manuals and user guides at all-guides.com USING AN iPod WITH THIS UNIT With an iPod connected (see Repeatedly press the FUNCTION previous page), if this unit is not button to select iPod mode; “iPod” already on, turn this unit on by will appear in the display.
  • Page 16 OPERATION (CONTINUED) All manuals and user guides at all-guides.com To navigate your iPod menus: To navigate your iPod menus At any time, press the MENU (continued): button to go back to the previous Use the Navigation UP 1 or screen/menu. Repeatedly press DOWN 2 button to browse the MENU button to return to the through the menus.
  • Page 17: Troubleshooting Guide

    TROUBLESHOOTING GUIDE All manuals and user guides at all-guides.com If you experience a problem with this unit, check the chart below before calling for service. SYMPTOM CAUSE SOLUTION No sound from iPod. Volume is Increase volume using set to minimum. VOL + / - buttons.
  • Page 18: Specifications

    All manuals and user guides at all-guides.com SPECIFICATIONS Power source ...............AC 120V/60Hz Power consumption: ..............120W Subwoofer impedance: ..............8 Ohm Surround impedance: ..............8 Ohm S/N: ....................60dB Subwoofer power output: ..............50W Left and Right speakers power output: ........15Wx2 THD (1KHz, 1W): .................0.5% Frequency response (Subwoofer): ......40Hz~200Hz 5dB Frequency response (Left and Right channels): ..200Hz~20KHz 5dB L/R separation (1KHz): ..............40dB...
