Abus PLHA10000 Instructions Manual

Z-wave 230v relay module
Hide thumbs Also See for PLHA10000:
Table of Contents

Advertisement

Quick Links

Download this manual
PLHA10000
Z-Wave 230V relay module
Important notes and FAQs about this product and other products can
be found on the Internet page
www.abus.com
Version 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLHA10000 and is the answer not in the manual?

Questions and answers

Related Manuals for Abus PLHA10000

Summary of Contents for Abus PLHA10000

  • Page 1 PLHA10000 Z-Wave 230V relay module Important notes and FAQs about this product and other products can be found on the Internet page www.abus.com Version 1.1...
  • Page 2 Software, or any breach by ABUS Security Center of its obligations under this Agreement.a. any warranty, contractual, statutory or compensatory damages claims, notwithstanding any other limited or implied warranties, or if the limited warranty does not apply, ABUS Security Center's liability shall be limited to the purchase price of the Product.

  • Page 3: Important Safety Instructions

    Please make sure that the packaging contains the DSK (Device Specific Key) card. This card shows the DSK of your ABUS Z-Wave device. Please keep them in a safe place. Each S2 (Security 2) certified Z-Wave Gateway requires the DSK to learn the device.
  • Page 4 English Children Do not allow electrical appliances to fall into the hands of children! Never allow children to use electrical equipment unattended. Children are not always able to recognize possible dangers correctly. Small parts can be life-threatening if swallowed. Keep packaging films away from children. There is a danger of suffocation! This device should not be handled by children.

  • Page 5: Table Of Contents

    English Table of contents Product Introduction ......................... 6 1.1. Scope of delivery ........................6 1.2. Device Features........................6 1.3. Operating Principle ........................6 1.4. performance characteristics ....................6 1.5. Use in systems of different manufacturers ................6 1.6. DSK Code ..........................6 Functional Overview .........................

  • Page 6: Product Introduction

    DSK card 1.2. Device Features 1.3. Operating Principle The PLHA10000 is designed for use in alarm and home automation systems using the Z-Wave radio standard. The device has the following functions:  two inputs S1 and S2 for connection to wall switches.

  • Page 7: Functional Overview

    English Hint: We recommend secure S2 inclusion (must be supported by the gateway) Please enter the 5 digits of the DSK code (bottom side of the device) or the entire DSK code (QR code) when prompted. 2. Functional Overview 2.1. Planning, assembly and installation The unit uses low-power radio signals to communicate with the Z-Wave Gateway.

  • Page 8: Inclusion (Inclusion) / Teach-In Device

    English 2.2. Inclusion (Inclusion) / Teach-in device Activate the inclusion mode (teach-in mode) on the gateway. (for further details please refer to the gateways manual) Press the "+" key (Add / Inclusion) in your Z-Wave app and follow the instructions to set the gateway to Inclusion mode.

  • Page 9: Exclusion (Exclusion) / Teach Device Out

    English 2.3. Exclusion (Exclusion) / Teach device out Activate the exclusion mode (learn-out mode) at the gateway. (for further details please refer to the gateways manual) Press the "-" key (Remove / Exclusion) in your Z- Wave app and follow the instructions to set the gateway to exclusion mode.

  • Page 10: Wake Up Device / Wake-Up

    English 2.5. Wake up device / Wake-up Press the Link button once to wake up the device. It then establishes a connection to the Z-Wave gateway and transmits the current status. 3. Advanced Z-Wave Parameters 3.1. Association Groups Z-Wave devices can control other devices directly. This direct control is called Z-Wave Association. The device ID of the device to be controlled must be stored in the controlling devices.

  • Page 11: Overview Configuration Parameters

    English Notification Report attribut Event Parameter Event Event type Length Parameters Device is supplied with power for the 0x08 0x00 0x01 first time Basic Commands command Description of the Basic Get Inquiry of the device status Basic Report Device condition report Switch device status (Value=0XFF On, Value 0x00 Off)...

  • Page 12: Technical Data

    English 4. Technical data parameter PLHA10000 Dimensions (W x H x D) 43 x 42 x 16.5 mm Weight 33 g Operating temperature >0° – 40°C IP class IP 20 (indoor) Radio frequency 868.42 MHz (Z-Wave PLUS, Europe) Modulation FSK (BFSK/GFSK) Transmission power: <...
