General Information

Rules to name TWC series

TWC- means tyre changer
T W C – 5 0 2 R D B +
Meaning of code:
①-
for rim clamping diameter: 4 stands for 10" ～19"(20");
②- for shape of turntable: 0 stands for round turntable;
③- post working mode: 1 stands for swing arm (semi-automatic);
2 stands for tilting arm(automatic);
3 stands for swivel arm (automatic)
④- for supplementary arm information: R stands for right supplementary arm;
⑤- for inflating device: I stands for inflating gun;
⑥- for inflating mode: B stands for quick inflator;
C stands for normal inflating;
⑦- for roller set: + stands for roller set;
For example:
TWC-502RDB+--------- the tyre changer's rim clamping diameter is 10"-23"(24"). It is equipped with round turntable, tilting
post(automatic), right supplementary arm, digital inflating box(LED display), quick inflator and roller set.
④
③
②
①
5 stands for 10" ～23"(24");
6 stands for 10" ～26";
1 stands for square turntable;
2 stands for cross turntable;
3 stands for asymmetric turntable;
L stands for left supplementary arm;
D stands for double supplementary arm;
N stands for none supplementary arm;
M stands for meter inflating box;
D stands for digital inflating gauge (LED display);
⑦
⑥
⑤
1
Tyre Changer(TWC Series)
