- Page 1 Hero Pixel Wash 760FX Moving Head...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 12.05.2023, ID: 557587...
-
Page 3: Table Of Contents
7.10 Functions in 34-channel DMX mode..............20 7.11 Functions in 23-channel DMX mode..............22 7.12 Functions in 51-channel DMX mode..............23 Technical specifications....................26 Plug and connection assignment................. 27 Troubleshooting........................28 Cleaning............................ 29 Protecting the environment................... 30 Hero Pixel Wash 760FX Moving Head... -
Page 4: General Information
The individual steps of an instruction are numbered consecutively. The result of a step is indented and highlighted by an arrow. Example: Switch on the device. Press [Auto]. ð Automatic operation is started. Switch off the device. Hero Pixel Wash 760FX Moving Head... -
Page 5: Symbols And Signal Words
Warning signs Type of danger Warning – high-voltage. Warning – hot surface. Warning – dangerous optical radiation. Warning – suspended load. Warning – danger zone. Hero Pixel Wash 760FX Moving Head... -
Page 6: Safety Instructions
The load capacity of trusses or other fixtures must be suffi‐ cient for the intended number of devices. Not that the movement of the head places additional loads on the load-bearing parts. Hero Pixel Wash 760FX Moving Head... - Page 7 Possible damage due to installation of a wrong fuse The use of different types of fuses can cause serious damage to the unit. Fire hazard! Only fuses of the same type may be used. Hero Pixel Wash 760FX Moving Head...
-
Page 8: Features
For technological reasons, the light output of LEDs decreases over their lifetime. This effect increases with higher operating temperature. You can extend the service life of the illuminants by providing adequate ventilation and operating the LEDs with the lowest possible brightness. Hero Pixel Wash 760FX Moving Head... -
Page 9: Installation
Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordinary microphone cables. Never connect the DMX input or output to audio devices such as mixers or amplifiers. Hero Pixel Wash 760FX Moving Head... - Page 10 Safety cables are threaded through the safety eyelets (B) on the bottom side of the housing. Please note that this device must not be connected to a dimmer. Hero Pixel Wash 760FX Moving Head...
-
Page 11: Starting Up
Connect the DMX output of the master device to the DMX input of the first slave device. Then connect the DMX output of the first slave device to the DMX input of the second slave device and so Hero Pixel Wash 760FX Moving Head... -
Page 12: Connections And Controls
11 [DMX Out] | DMX output, designed as XLR panel socket, 5-pin 12 Fuse holder 13 [Power In] | Lockable input socket (Power Twist) for mains power supply 14 [Power Out] | Lockable output socket (Power Twist) for powering a connected device Hero Pixel Wash 760FX Moving Head... -
Page 13: Operating
[ESC], [SET], [UP] or [DOWN] will then turn it back on. 7.3 Device settings Operating mode The device can be operated with a DMX controller or as an independent host. Open the main menu. Navigate to ‘Fixture è Run Mode’. Hero Pixel Wash 760FX Moving Head... - Page 14 ‘23CH’ 23-channel mode ‘51CH’ 51-channel mode Setting DMX signal mode You can specify how the device should behave in case of DMX signal loss. Open the main menu. Navigate to ‘Fixture è Dmx Signal’. Hero Pixel Wash 760FX Moving Head...
- Page 15 ‘Pan’ ‘000…255’ Adjusts the rotation angle. ‘Pan Fine’ ‘000…255’ Adjusts the fine range of the rotation angle. ‘Tilt’ ‘000…255’ Adjusts the tilt angle. ‘Tilt Fine’ ‘000…255’ Adjusts the fine range of the tilt angle. Hero Pixel Wash 760FX Moving Head...
-
Page 16: Default Settings
Sets the home position for zoom rotation. ‘Red’ ‘000…255’ Sets the initial intensity for red. ‘Green’ ‘000…255’ Sets the initial intensity for green. ‘Blue’ ‘000…255’ Sets the initial intensity for blue. ‘White’ ‘000…255’ Sets the initial intensity for white. Hero Pixel Wash 760FX Moving Head... -
Page 17: System Information
7.6 Device reset If necessary, it is possible to fully reset the device, or to reset the motor drive on its own. Open the main menu. Navigate to ‘Fixture Reset’. Hero Pixel Wash 760FX Moving Head... -
Page 18: Display Settings
‘Normal’ Sets the display orienta‐ tion to normal. ‘Reverse’ Sets the display orienta‐ tion to reverse. ‘Display Mode’ ‘60 s’ Sets the display activity to 60 s. ‘Show’ Sets the display activity to permanent. Hero Pixel Wash 760FX Moving Head... -
Page 19: Menu Overview
Green 000 - 255 Blue 000 - 255 White 000 - 255 Motor Reset Cancel / Run Fixture Reset Factory Cancel / Run Display Flip Normal / Reverse Display Display Mode 60s / Show Hero Pixel Wash 760FX Moving Head... -
Page 20: Functions In 9-Channel Dmx Mode
Blue intensity, 0 to 100% 000…255 Fine adjustment of blue intensity 000…255 White intensity, 0 to 100% 000…255 Fine adjustment of white intensity 000…255 Intensity of colour temperature sequence 000…255 Colour macros Strobe 000…003 LEDs off Hero Pixel Wash 760FX Moving Head... - Page 21 Intensity of white form effect 000…255 Intensity of form effect, 0 to 100% 000…255 Background intensity, 0 to 100% 000…255 Transition of form effect 000…255 Dip of form effect 000…255 Strobe intensity in the foreground Hero Pixel Wash 760FX Moving Head...
-
Page 22: Functions In 23-Channel Dmx Mode
Red intensity, 0 to 100% 000…255 Green intensity, 0 to 100% 000…255 Blue intensity, 0 to 100% 000…099 White intensity, 0 to 100% 000…255 Intensity of colour temperature sequence 000…255 Colour macros 000…255 Static effect 000…255 Dynamic effect Hero Pixel Wash 760FX Moving Head... -
Page 23: Functions In 51-Channel Dmx Mode
Strobe effect (low speed) 226…238 Strobe effect (medium speed) 239…251 Strobe effect (high speed) 252…255 LEDs on 000…255 Red intensity, 0 to 100% 000…255 Green intensity, 0 to 100% 000…255 Blue intensity, 0 to 100% Hero Pixel Wash 760FX Moving Head... - Page 24 White intensity, segment 5, 0 to 100% 000…255 Red intensity, segment 6, 0 to 100% 000…255 Green intensity, segment 6, 0 to 100% 000…255 Blue intensity, segment 6, 0 to 100% 000…255 White intensity, segment 6, 0 to 100% Hero Pixel Wash 760FX Moving Head...
- Page 25 Value Function 000…255 Red intensity, segment 7, 0 to 100% 000…256 Green intensity, segment 7, 0 to 100% 000…257 Blue intensity, segment 7, 0 to 100% 000…258 White intensity, segment 7, 0 to 100% Hero Pixel Wash 760FX Moving Head...
-
Page 26: Technical Specifications
11.5 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20%…80% (non-condensing) Further information Light source type Light output 420 W Colour mix RGBW Motorised focus Motorised zoom Static gobos Rotating gobos Iris Prism Hero Pixel Wash 760FX Moving Head... -
Page 27: Plug And Connection Assignment
The drawing below and the table show the pin assignment of a matching coupling. Assignment Ground (shielding) Signal inverted (DMX–, ‘cold’) Signal (DMX+, ‘hot’) unused / second connection (DMX–) unused / second connection (DMX+) Hero Pixel Wash 760FX Moving Head... -
Page 28: Troubleshooting
DMX interface cir‐ cuit. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. Hero Pixel Wash 760FX Moving Head... -
Page 29: Cleaning
Before cleaning, switch off the device and disconnect mains-oper‐ ated devices from the mains. Only use pH-neutral, solvent-free and non-abrasive cleaning agents. Clean the unit with a slightly damp lint-free cloth. Hero Pixel Wash 760FX Moving Head... -
Page 30: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. Hero Pixel Wash 760FX Moving Head... - Page 32 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
