1. Unpack the HL23T-PRO

The box contains the following items:
A. Enclosure × 1
B. Thunderbolt 3 cable (0.5 meter) × 1
C. Power cord × 1
2. Panel Layout
1. Power-On Indicator LED
。This power-on indicator LED only indicates power state.
When HL23T-PRO is powered on, it shows blue. When
enclosure is powered off, it shows no light.
2. Thunderbolt 3 Port
。The Thunderbolt 3 port on HL23T-PRO will be
connected to the host computer.
3. Graphics/GPU card slot
4. Thumbscrew for loosening/tightening
the top cover
5. Power cord receptacle
2
3
1
4
3
5
