TPA152 Audio Power Amplifier Evaluation Module User’s Guide SLOU019 June 1998 Printed on Recycled Paper...
Page 3
IMPORTANT NOTICE Texas Instruments (TI) reserves the right to make changes to its products or to discontinue any semiconductor product or service without notice, and advises its customers to obtain the latest version of relevant information to verify, before placing orders, that the information being relied on is current.
Page 4
SLOU011) provides detailed information on the evaluation platform and its use with TI audio evaluation modules. TPA152 75-mW STEREO AUDIO POWER AMPLIFIER (literature number SLOS210) This is the data sheet for the TPA152 audio amplifier integrated circuit. FCC Warning This equipment is intended for use in a laboratory test environment only.
Page 5
Send a fax to MSP Marketing Documentation or any other TI documentation Correction: (972) 480–3160 Or send your comments to: Texas Instruments Incorporated MSP Marketing Documentation, MS 8710 P.O. Box 660199 Dallas, Texas 75266–0199 † Texas Instruments Product Information Center...
............Using The TPA152 EVM With The Plug-N-Play Evaluation Platform .
Page 7
......3-11 Tables 2–1 Typical TI Plug-N-Play Platform Jumper and Switch Settings for the TPA152 EVM ..2–2 Platform Jumper and Switch Settings for the TPA152 EVM .
Chapter 1 Introduction This chapter provides an overview of the Texas Instruments (TI ) TPA152 Audio Amplifier Evaluation Module (SLOP123). It includes a list of EVM features, a brief description of the module illustrated with a pictorial diagram, and a list of EVM specifications.
Page 10
Features 1.1 Features The TI TPA152 Audio Amplifier Evaluation Module and the TI Plug-N-Play Audio Amplifier Evaluation Platform include the following features: TPA152 Stereo Audio Power Amplifier Evaluation Module Dual channel, single-ended operation 75 mW output power into 32 Ω at 5 V 4.5-V to 5.5-V operation...
Evaluation Platform, or to be wired directly into existing circuits and equipment when used stand-alone. The platform has room for a single TPA152 evaluation module and is a convenient vehicle for demonstrating TI’s audio power amplifier and related evaluation modules. The EVMs simply plug into the platform, which...
The platform switch and jumper settings shown in Table 2–1 are typical for the TPA152 EVM and will cause the TPA152 IC to mute when a plug is removed from platform headphone jack J10. Table 2–1. Typical TI Plug-N-Play Platform Jumper and Switch Settings for the TPA152...
Precautions 2.1 Precautions Power Supply Input Polarity and Maximum Voltage Always ensure that the polarity and voltage of the external power connected to V power input connector J1, J2, and/or V power input connector J6 are correct. Overvoltage or reverse-polarity power applied to these terminals can open on-board soldered-in fuses and cause other damage to the platform, installed evaluation modules, and/or the power source.
1) Ensure that all external power sources are set to OFF and that the platform power switch S1 is set to OFF. 2) Install a TPA152 module in platform socket U5, taking care to align the module pins correctly. 3) Use switch S2 to select or bypass the signal conditioning EVM (U1) 4) Set control signal Polarity jumper JP7 to Lo.
Quick Start List for Stand-Alone 2.3 Quick Start List for Stand-Alone Follow these steps to use the TPA152 EVM stand-alone or when connecting it into existing circuits or equipment. Connections to the TPA152 module header pins can be made via individual sockets, wire-wrapping, or soldering to the pins, either on the top or the bottom of the module circuit board.
Chapter 3 Details This chapter provides details on the TPA152 IC, the evaluation module, the steps in the Quick-Start List, additional application information, and a parts list for the TPA152 evaluation module. Topic Page Precautions 3–2 The TPA152 Audio Power Amplifier Evaluation Module 3–3...
Precautions 3.1 Precautions Power Supply Input Polarity and Maximum Voltage Always ensure that the polarity and voltage of the external power connected to V power input connector J1, J2, and/or V power input connector J6 are correct. Overvoltage or reverse-polarity power applied to these terminals can open on-board soldered-in fuses and cause other damage to the platform, installed evaluation modules, and/or the power source.
3.2 The TPA152 Audio Power Amplifier Evaluation Module The TPA152 Audio Power Amplifier Evaluation Module is powered by a TPA152 75-mW Stereo Audio Amplifier IC, includes a mute control signal input with on-board switch, and can drive either 32-Ω headphones or line-level outputs.
The TPA152 Audio Power Amplifier Evaluation Module 3.2.1 TPA152 Audio Amplifier IC The TPA152 audio amplifier IC is a CMOS device intended primarily for high-performance line-level output and headphone driver applications. It is supplied in a very small surface-mount package and has been designed to operate from low supply voltages (between approximately 4.5 V and 5.5 V)
3.2.3 Mute When the mute terminal of the TPA152 amplifier IC is taken high, the IC ceases operation. This is accomplished by applying a control signal to the module SD pin or by pressing the Shutdown switch, S1, on the module. When the control signal goes low or is removed (or the switch is released), amplifier operation resumes.
Using The TPA152 EVM With the Plug-N-Play Evaluation Platform 3.3 Using The TPA152 EVM With the Plug-N-Play Evaluation Platform The TPA152 Audio Amplifier Evaluation Module was designed to be used with the TI Plug-N-Play Audio Amplifier Evaluation Platform. It simply plugs into socket U5.
The audio signal from the input jacks can be applied to the signal conditioning socket (U1) if an EVM is installed there, or socket U1 can be bypassed and the audio input signal applied directly to the inputs of the TPA152 power amplifiers. Switch S2 selects or bypasses signal conditioning.
Using The TPA152 EVM With the Plug-N-Play Evaluation Platform 3.3.3 Mute The TPA152 EVM is equipped with a mute control input pin. When this input is tied to V , the TPA152 amplifier IC on the module ceases operation. When the EVM control input is tied to GND or allowed to float, amplifier operation resumes.
J6 MUST NOT exceed the absolute maximum rating for the TPA152 amplifier IC installed on the evaluation module (5.5 V), or damage to the IC may result. In no case should V voltage of the incorrect polarity or in excess of 6.1 V be applied...
J10 to the output lines of either the headphone amplifier socket or the power amplifier sockets (Figure 3 – 5). When the TPA152 output signal is routed to J10 by S3, signals output via J10 are returned to platform ground when a plug is inserted (Figure 3 –...
Using The TPA152 EVM Stand-Alone 3.4 Using The TPA152 EVM Stand-Alone Using the TPA152 Audio Power Amplifier Evaluation Module stand-alone is much the same as using it with the platform. The same 4.5-V to 5.5-V power supply requirement exists. Note that the mute signal applied to the EVM SD pin must be able to supply enough current to overcome the pulldown resistor on the module (20 kΩ).
TPA152 Audio Power Amplifier Evaluation Module Parts List 3.5 TPA152 Audio Power Amplifier Evaluation Module Parts List Table 3–1. TPA152 EVM Parts List Manufacturer/ Ref. Description Size Vendor/Number Qty. Part Number Capacitor, 1 µF, 6.3 V C1, C3, 1206 Murata...
