Backyard Discovery
3001 North Rouse
Pittsburg, KS 66762
1-800-856-4445
• Owner's Manual
• Frequently Asked Questions
• Assembly Instructions
• Warranty Information
www.swingsetsonline.com (you will also find any updates on
assembly instructions and information to order replacement parts)
Features the
Save this assembly manual for future reference in the event that
INS-6315-A-VERTICAL GARDEN-ENG 8/29/14
VERTICAL GARDEN
OUTDOOR PRODUCT
Register your new (Outdoor Product) on-line @
you need to order replacement parts.
MODEL: 6315
fastening system.
Made in China
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Backyard Discovery 6315
Summary of Contents for Backyard Discovery 6315
- Page 1 (you will also find any updates on assembly instructions and information to order replacement parts) Features the fastening system. Save this assembly manual for future reference in the event that you need to order replacement parts. Made in China INS-6315-A-VERTICAL GARDEN-ENG 8/29/14...
- Page 2 STOP PARE Missing A Part? CALL US BEFORE GOING BACK TO THE STORE! The store where you made your purchase does not stock parts for this item. If you have assembly questions or if you need parts, whether they are missing or damaged Call Toll-Free Help Line or visit www.swingsetsonline.com ¡LLÁMENOS ANTES DE REGRESAR A LA TIENDA! La tienda donde realizó...
- Page 3 Owner’s Manual Outdoor Product Dear Customer: Please read entire booklet completely before beginning the assembly process. Structures are not intended for public use. The Company does not warranty any of its residential structures subjected to commercial use such as: Recreational Park, or any similar Commercial Application.
- Page 4 Outdoor Product Assembly Manual FAQs: 1. Is the wood treated with chemicals? Backyard Discovery uses 100% Chinese Cedar wood which is naturally bug resistant, decay and rot resistant. To help ensure your families safety, our wood is completely chemical free and we do not use pressure-treated wood.
- Page 5 Owner’s Manual Outdoor Product Maintenance Instructions: 1. Check all nuts and bolts twice monthly during the usage season and tighten as required. (But not so tight that you crack the wood) It is particularly important that this procedure be followed at the beginning of each season. 2.
-
Page 6: Tools Required For Installation
Tools Required for Installation: (These are the tools that are generally required for assembly of our outdoor products. These tools are not included with the outdoor product purchase.) (Square) (Cordless Drill or Electric Drill) (Drill Attachments: (Phillips Screw Driver) Phillips Head) (An Adult w/ an Adult Helper) - Page 7 Basic Setup Dimensions 48 13/16" 33" 15 11/16" Important Assembly Notes 1) While assembling unit, take time before and after each phase to make sure unit is level. If unit is not level, assembly will be difficult and improper assembly may result. Extra care must be taken to ensure the unit is square.
-
Page 8: Parts Identification
Parts Identification Wood Components (NOT TO SCALE) N1 - FACE BOARD - W4L05269 5/8"x1 5/8"x37 5/8" (16x40x956) M1 - HEADER - W4L05270 5/8"x3 3/8"x31 3/4" (16x86x806) K1 - SUPPORT BOARD - W4L05272 5/8"x4 3/4"x14 5/8" (16x120x370) N3 - DOOR TRIM - W4L05273 5/8"x1 5/8"x33"... - Page 9 Parts Identification Wood Components (NOT TO SCALE) K5 - BACK BOARD - W4L05278 5/8"x5 1/4"x30 1/2" (16x134x774) L1 - BOTTOM BOARD - W4L05279 5/8"x4 1/8"x30 1/2" (16x106x774) K6 - TOP BOARD - W4L05280 5/8"x5 1/4"x30 1/2" (16x134x774) T1 - FLOOR SUPPORT - W4L05281 1"x1 3/8"x28 5/8"...
- Page 10 Parts Identification Hardware (48) VT - SCREW PFH 8x1-1/2 BLK - H100200 - NUT BARREL WH 1/4x5/8 BLK - H100404 (60) - SCREW PFH 8x1 1/4 BLK - H100387 - BOLT WH 1/4x1/2 BLK - H100401 (10) - SCREW PFH 8x1 1/8 BLK - H100386 (11) VW - SCREW PFH 8x1/2 BLK - H100203 - WASHER LOCK EXT 6x15 BLK - H100405...
- Page 11 K1 - SUPPORT BOARD - W4L05272 WP1 - LEFT SIDE PANEL- W2A01672 5/8"x4 3/4"x14 5/8" (16x120x370) 1 1/2"x9 3/4"x45 .75" (40x248x1162) STEP 1 SCREW PFH 8x1 1/8 BLK SCREW PFH 8x1 1/8 BLK (4 PLCS)
- Page 12 WP2 - RIGHT SIDE PANEL- W2A01673 K1 - SUPPORT BOARD - W4L05272 1 1/2"x9 3/4"x45 .75" (40x248x1162) 5/8"x4 3/4"x14 5/8" (16x120x370) STEP 2 SCREW PFH 8x1 1/8 BLK SCREW PFH 8x1 1/8 BLK (4 PLCS)
- Page 13 L1 - BOTTOM BOARD - W4L05279 K5 - BACK BOARD - W4L05278 5/8"x4 1/8"x30 1/2" (16x106x774) 5/8"x5 1/4"x30 1/2" (16x134x774) T1 - FLOOR SUPPORT - W4L05281 K6 - TOP BOARD - W4L05280 1"x1 3/8"x28 5/8" (24x34x726) 5/8"x5 1/4"x30 1/2" (16x134x774) STEP 3 SCREW PFH 8x1-1/2 BLK (44 PLCS)
- Page 14 K4 - FLOOR BOARD - W4L05277 5/8"x5 1/4"x30 1/2" (16x134x774) STEP 4 SCREW PFH 8x1 1/4 BLK (4 PLCS) SCREW PFH 8x1 1/4 BLK...
- Page 15 N5 - DOOR TRIM - W4L05457 5/8"x1 5/8"x33" (16x42x838) SQ - "A" REVISION TAG - A100314 N3 - DOOR TRIM - W4L05273 - 90° L-BRACKET - BLK - A4M00555 5/8"x1 5/8"x33" (16x42x838) STEP 5 SCREW PFH 8x1/2 BLK SCREW PWH 8x5/8 BLK NUT BARREL WH 1/4x5/8...
- Page 16 K2 - DOOR BOARD - W4L05274 - HINGE - A4M00583 - KNOB - MED BROWN - A6P00080 5/8"x5 1/8"x33" (16x130x838) STEP 6 SCREW PFH 8x1 1/8 BLK SCREW PFH 8x1 1/8 BLK (1 PLCS) KNOB - MED BROWN (1 PLCS) HINGE WITH INCLUDED SCREWS (2 PLCS)
- Page 17 K3 - SHELF BOARD - W4L05275 5/8"x5 1/4"x30 1/2" (16x134x774) STEP 7 SCREW PFH 8x1 1/4 BLK SCREW PFH 8x1 1/4 BLK (4 PLCS)
- Page 18 N4 - SHELF BOARD - W4L05276 K3 - SHELF BOARD - W4L05275 5/8"x2 3/8"x30 1/2" (16x60x774) 5/8"x5 1/4"x30 1/2" (16x134x774) STEP 8 SCREW PFH 8x1 1/4 BLK SCREW PFH 8x1 1/4 BLK (6 PLCS)
- Page 19 N4 - SHELF BOARD - W4L05276 K3 - SHELF BOARD - W4L05275 5/8"x2 3/8"x30 1/2" (16x60x774) 5/8"x5 1/4"x30 1/2" (16x134x774) STEP 9 SCREW PFH 8x1 1/4 BLK (30 PLCS) SCREW PFH (30) 8x1 1/4 BLK...
- Page 20 S1 - FRONT SUPPORT - W4L05282 N1 - FACE BOARD - W4L05269 1"x1"x2" (24x24x50) 5/8"x1 5/8"x37 5/8" (16x40x956) STEP 10 SCREW PFH 8x1 1/4 BLK (6 PLCS) SCREW PFH 8x1 1/4 BLK 2 1/2 17 1/2...
- Page 21 FACE BOARD SUB ASSEMBLY STEP 11 SCREW PFH 8x1 1/4 BLK SCREW PFH 8x1 1/4 BLK (6 PLCS)
- Page 22 M1 - HEADER - W4L05270 5/8"x3 3/8"x31 3/4" (16x86x806) - 90° L-BRACKET - BLK - A4M00555 STEP 12 NOTE: PILOT HOLE SCREW PFH 8x1/2 BLK SCREW PFH 8x1/2 BLK (2 PLCS)
- Page 23 HEADER ASSEMBLY STEP 13 SCREW PFH 8x1/2 BLK SCREW PFH 8x1/2 BLK (2 PLCS)
- Page 24 VJ - LTP ID TAG (SMALL) WITHOUT AGES - A100387 STEP 14 SCREW PFH 8x1/2 BLK (2 PLCS) SCREW PFH 8x1/2 BLK...
- Page 25 Owner’s Manual Outdoor Product Maintenance Instructions: 1. Check all nuts and bolts twice monthly during the usage season and tighten as required. (But not so tight that you crack the wood) It is particularly important that this procedure be followed at the beginning of each season. 2.
Need help?
Do you have a question about the 6315 and is the answer not in the manual?
Questions and answers
how do you use the vertical garden?
To use the Backyard Discovery Vertical Garden Model 6315:
1. Assemble the Unit: Follow the assembly instructions using the correct hardware and parts listed (e.g., face boards, header, support boards, shelf boards). Ensure T-nuts are inserted properly and bolts are not over-tightened.
2. Mount Planters: Once assembled, place plants or planters on the shelves provided.
3. Maintenance: The wood is not pressure-treated, so apply a water- or oil-based stain once each year to maintain appearance and durability.
4. Care for Wood: Expect natural wood checks due to weather; these do not affect strength.
5. Warranty: The product includes a 1-year replacement warranty for manufacturer defects.
For missing or damaged parts, contact the help line or visit the website listed in the manual.
