Connecting New Devices - Targus Universal Notebook Docking Station with Video ACP50 User Manual

Targus Universal Notebook Docking Station with Video
• Green Tx light illuminates when connected to a
network and the yellow Rx light flashes when data is
transmitting to or from the network.
NOTE: T
.
CABLE
• USB lights will glow when the docking station is
connected to your computer.
• Always On LED glows green when button is depressed.
Laptop
Support
Pad
Audio Audio
In Out

Connecting New Devices

To avoid possible damage when connecting a new
device, do not force the cable connector into the port on
the docking station. If the cable connector does not
attach smoothly, turn the connector over and try attaching
it again.
Connecting a Serial Mouse
To connect a serial mouse, attach the cable connector to
the serial port on the docking station.
HE DOCKING STATION SUPPORTS HOT SWAPPING OF THE NETWORK
Serial
VGA
Network
Docking Station Ports
Laptop Support Pad
USB Ports
Always On
8
AC Adapter
USB to PC
Connection
