Summary of Contents for Targus ACP45
-
Page 1: User Guide
Universal Laptop Docking Station USER GUIDE... -
Page 2: Table Of Contents
System Requirements... 5 Installing the Device and Drivers... 6 Connecting New Devices... 11 Global Suspend Mode... 16 Targus Always On... 17 Using USB Devices That Require More Power ... 17 Product Limitations... 17 Troubleshooting ... 18 Technical Support ... 20 Product Registration... -
Page 3: Targus Universal Laptop Docking Station
USB specification for higher power requirement devices, and USB ports that are widely spaced to acommodate larger adapters. Targus Always On provides power to the USB ports even when the laptop is shut-down, disconnected from the docking station or in hibernate/ stand-by mode. - Page 4 Targus Universal Laptop Docking Station Features Heat dissipation by natural convection: Place the back edge of your laptop on the rubber pads of the Docking Station. Most laptops dissipate heat through the bottom and the more air that’s allowed to flow under the bottom, the better chance that heat will dissipate by natural convection.
-
Page 5: Package Contents
Targus Universal Laptop Docking Station Package Contents In addition to this user guide, the package contains: • Targus Universal Laptop Docking Station • High-speed USB 2.0 upstream cable • Driver software CD • AC power adapter System Requirements Hardware • PC with an Intel •... -
Page 6: Installing The Device And Drivers
Targus Universal Laptop Docking Station Installing the Device and Drivers To use the Targus docking station, you must first install the driver onto your computer. WARNING: Y OU MUST INSTALL THE SOFTWARE DOCKING STATION TO YOUR COMPUTER WILL NOT WORK PROPERLY... - Page 7 Targus Universal Laptop Docking Station 3 The Installation Wizard window of the docking station will pop up. Click Next to proceed. 4 The Information window will pop up. Click Next to proceed. In order to install the driver files properly, you must restart your system before plugging in the docking station.
- Page 8 Targus Universal Laptop Docking Station 5 Choose Yes, I want to restart my computer now. Click Finish and restart your computer when prompted. Connecting the Docking Station to Your Computer After installing the docking station software, you are ready to connect the docking station to your computer. To...
-
Page 9: Led Status Indicator Lights
Targus Universal Laptop Docking Station Installing the Default Device Drivers Once you connect the docking station to your computer, the default drivers begin installing for each of the ports automatically. NOTE: P LEASE ENSURE YOU HAVE THE LATEST SERVICE PACKS INSTALLED Some hardware devices may prompt you to install the drivers. - Page 10 Targus Universal Laptop Docking Station Laptop Support Pad Parallel PS/2 “Easy Access” High-Speed USB 2.0 Port Targus DEFCON CL, PA410U (not included) Docking Station Left-Side View Docking Station Right-Side View Network Serial S/PDIF Audio In Audio Out Audio In Audio Out...
-
Page 11: Connecting New Devices
Targus Universal Laptop Docking Station Connecting New Devices To avoid possible damage when connecting a new device, do not force the cable connector into the port on the docking station. If the cable connector does not attach smoothly, turn the connector over and try attaching it again. -
Page 12: Connecting To A Local Area Network
Targus Universal Laptop Docking Station Connecting a Parallel Printer To connect a parallel printer: 1 Attach the cable connector to the parallel port on the docking station. 2 Go to Start button of your Window OS, and click on Printers and Faxes. Add your printer driver by following the instructions of the Add Printer Wizard. -
Page 13: Connecting A Usb Device
USB ports on the right side denoted by this symbol have two unique features - Always On and High Power. See “Targus Always On” on page 17 for more details, and “Using USB Devices That Require More Power” on page 17. - Page 14 Targus Universal Laptop Docking Station Click Apply, then click OK. For Windows XP, go to the Control Panel and choose Sound and Audio. Select the Audio tab. Under Sound Playback, change Preferred Device to USB PnP Sound Device from the drop down list.
- Page 15 Targus Universal Laptop Docking Station Installing and Configuring a S/PDIF (Sony/ Philips Device 1 In order to enable S/PDIF, you have to turn it on. This can be done by opening the USB 3D Sound Configuration applet located in your system tray (click on the USB icon to open up the Configuration Screen).
-
Page 16: Global Suspend Mode
Targus Universal Laptop Docking Station 4 Plug your optical cable (not included) into the S/PDIF-Out port of docking station on one end, and the S/PDIF-In port of Digital Decoder or Speaker on the other end. Universal Docking Station ZOOM IN... -
Page 17: Targus Always On
Targus Universal Laptop Docking Station Targus Always On The two USB ports that provide up to 1 Amp of power will continue providing power even when the laptop is powered down or disconnected from the docking station. This allows you to charge any USB device you connect to these ports without powering your laptop. -
Page 18: Troubleshooting
Targus Universal Laptop Docking Station Troubleshooting Device Not Working • Make sure that the device is fully inserted into the correct port on the docking station. • Plug the device into a different port on the docking station. If it still doesn’t work, test the device by connecting it directly to your computer. - Page 19 Targus Universal Laptop Docking Station Right-click My Computer, Properties, then click the Hardware tab, and then the Device Manager button. From the Device Manager window, expand the following: • Human Interface Devices - displays keyboards and pointing devices: mice, trackballs, and joysticks •...
-
Page 20: Technical Support
Targus Universal Laptop Docking Station Error Message on Your PDA If the error message “Connection Not Established” appears on your PDA, check that the COM port setting in either your HotSync or ActiveSync software matches the setting on the docking station. See “Verifying Devices are Installed”... -
Page 21: Product Registration
Under no conditions is Targus liable for loss of, or damage to a computer; nor loss of, or damage to, programs, records, or data; nor any consequential or incidental damages, even if Targus has been informed of their possibility. -
Page 22: Fcc Statement
Targus Universal Laptop Docking Station including interference operation. FCC Statement Tested to Comply This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to... - Page 23 Microsoft Corporation in the United States and/or other countries. All trademarks and registered trademarks are the properties of their respective owners. All rights reserved. Features and specifications subject to change without notice. © 2008, Targus Group International, Inc. and Targus, Inc, Anaheim, CA 92806 USA.
- Page 24 Visit our website at www.targus.com Features and specifications are subject to change without notice. © 2008 Targus Group International, Inc. and Targus, Inc, Anaheim, CA 92806 USA. ACP45US / 410-0391-001C...
