molex Core Sync Installation Instructions

Modules must be installed by a qualified electrician.
1. Caution: Observe precautions for handling electrostatic sensitive sensors.
2. WARNING: Risk of electric shock. Do not handle energized module with wet hands or when standing
on wet or damp surfaces.
3. WARRANTY: Voided if module has been modified from original configuration.
4. Suitable for damp locations.
5. Do not use Outdoors.
6. Use only with Class 2 Power Unit – 60VDC maximum.
7. Conforms UL 60730-1, CAN/CSA-E60730-1.
8. Suitable for Use in Other Environmental Air Space (Plenums) in accordance with Section 300.22, (C) of
the National Electrical Code
9. This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
10. Maximum temperature is 30°C ambient.
11. Input: PoE voltage range of 42-57V.
12. For CSA, device is intended to be installed in a restricted access area.
13. The mounting pattern for the module is below:
987652-1032
1 | P a g e
Installation Instructions
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
Core Sync – Interface Module
(Check with local and national codes for proper installation)
