Box Contents

• 1 x C Series Driver including:
• 1 x Loop connectors (2x for C5-2, C7-2)
• 1 x DC connector
• 2 x Input connectors
• 1 x 100V line connector
• 1 x Line out connector
• 2 x 2mm steel 1U rack mount brackets
This symbol is used to alert the user to important operating or maintenance instructions.
The Lightning bolt triangle is used to alert the user to the risk of electric shock.

1. SAFETY

1. It is important to read these instructions, and to follow them.
2. Keep this quick start guide in an accessible place.
3. Clean only with a dry cloth. Cleaning fluids may affect the equipment.
4.
Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
5. Do not install this equipment near any heat sources such as radiators, heating vents or other apparatus
that produces heat.
6.
WARNING – THIS APPARATUS MUST BE EARTHED / GROUNDED.
7. Only power cords with the correct power connector may be used to maintain safety. Cables incorporating
the UK 13A fused plug, Schuko with earthing contacts and UL approved "grounding type" are acceptable.
These must be plugged into power outlets which provide a protective earth.
8. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in
any way, such as a power supply cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to any rain or moisture, does not operate normally
or has been dropped.
9.
WARNING – To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture. The apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
10.
Warning: Connection to a 100V line system may involve the risk of electric shock and therefore
must be carried out by an instructed or skilled person.

2. TOOLS AND EQUIPMENT

Small hand tools including a wire stripper, small flat blade and posi screwdrivers will be required.
A magnetic field strength meter, Loopworks Measure App & R1 Reciever, or at minimum an induction loop
receiver is vital to check that the loop system is providing the desired level of performance.
Ampetronic C Series Quick Start Guide
C Series Quick Start Guide
ERROR
AGC (dB)
CURRENT (A pk)
36
CH A
28
20
12
TO PREVENT ELECTRIC SHOCK DO NOT REMOVE THE
COVER. THERE ARE NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL
+12V
• Also includes:
• 1 x C Series quick start guide
• 1 x Power cable (region specific)
• 1 x Induction Loop Sign
• 4 x self adhesive feet
CLIP
9.0
CH B
4.5
2.3
1.2
Serial No.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ampetronic C Series

  • Page 1 TO PREVENT ELECTRIC SHOCK DO NOT REMOVE THE COVER. THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL 2. TOOLS AND EQUIPMENT Small hand tools including a wire stripper, small flat blade and posi screwdrivers will be required. Serial No. +12V A magnetic field strength meter, Loopworks Measure App & R1 Reciever, or at minimum an induction loop receiver is vital to check that the loop system is providing the desired level of performance. Ampetronic C Series Quick Start Guide Page 1...
  • Page 2 • Input Gain Channel 1 -80.0dB • Ethernet Parameters Set by DHCP • Input Gain Channel 2 -80.0dB 5. ADDITIONAL FEATURES • Home screen timeout – if no action is taken in a mode screen after 30s the home screen is displayed. For a value screen the timeout is 60s. • Sleep mode – After a 10 minute period of user or audio inactivity the driver turns on the ‘Loop outputs disabled’ test signal and turns off the screen to save power. The Status led flashes green to indicate this. Any user activity or presence of audio signal brings the driver out of sleep. The inactivity time can be changed via the website (where network option fitted) • Lock screen – A long press on the home button brings up the lock menu. This gives access to standby, re-start (same as in settings menu) & lock. Selecting lock makes the user controls inactive. Any user input results in a padlock being displayed. To unlock the unit press the home button six times. Unlock instructions are shown briefly when lock is selected. • Standby – This is a user imposed sleep. Only user activity (not audio signal) brings the driver out of standby. Page 2 Ampetronic C Series Quick Start Guide...
  • Page 3 New IP Address XXX.XXX.XXX.XXX A new Ethernet address has been assigned to the driver. This can occur when an Ethernet cable is plugged into the driver or the DHCP system re-assigns a new IP address. These messages appear in the status menu when the associated error is present: Power Limit - derated: The driver is overloaded and the drive current has been reduced Loop A open circuit: The driver has detected an open circuit on loop A. Loop B open circuit: The driver has detected an open circuit on loop B. Temp Limit - derated: The internal heatsink is too hot and the driver current on both channels has been reduced. Temp Limit - muted: The internal heat sink has reached an unacceptable level and outputs have been turned off. Ampetronic C Series Quick Start Guide Page 3...
  • Page 4 2014 / 30 / EU The Electromagnetic Compatibility Directive and its amending directives 2011 / 65 / EU The RoHS Directive and its amending directives and has been designed and manufactured to the following specifications: Safety Standards: EN 62368-1 / Audio, video and similar electronic apparatus – Safety requirements UL 62368-1 EMC Standards: EN 55032 EMC – Product family standard for multimedia equipment: Emission EN 55035 EMC – Product family standard for multimedia equipment: Immunity Date: August 2018 J.R. Pieters Managing Director, Ampetronic Ltd. CAUTION: Changes or modifications not expressly approved by Ampetronic or an authorised partner could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at their own expense. Page 4 Ampetronic C Series Quick Start Guide...
