Elkay LZO Series Installation, Care & Use Manual
Sensor-operated water coolers with flexi-guard
Hide thumbs
Also See for LZO Series:
- Installation & use manual (6 pages) ,
- Installation & user manual (9 pages) ,
- Installation, care & use manual (7 pages)
Related Manuals for Elkay LZO Series
Summary of Contents for Elkay LZO Series
- Page 1 LZO8*1G LZO8*2G LZO8*3G LZOD*1D INSTALLATION, CARE & USE MANUAL LZO™ Series Sensor-Operated Water Coolers Model LZO8L Page 1 1000003094 (Rev. B - 11/16)
- Page 2 LZO8*1G LZO8*2G LZO8*3G LZOD*1D Note: Danger! Electrical shock hazard. Disconnect power before servicing unit. Uses HFC-134A refrigerant See Fig. 5 Sensor Eye Adjustment screw See Fig. 4 See Note 8 Stream Height Adjustment Screw FIG. 1 1000003094 (Rev. D - 11/16) Page 2...
- Page 3 LZO8*1G LZO8*2G LZO8*3G LZOD*1D FIG. 2 Page 3 1000003094 (Rev. B - 11/16)
- Page 4 CAUTION: Complete range of sensor (24-36 inches/610-1168mm) is only one turn of the adjusting screw. SENSOR WITH VISUAL FILTER MONITOR (VFM) – LZO SERIES: The electronic sensor includes LED filter status indicators that are factory preset to monitor filter life. The sensor monitors the “ON”...
- Page 5 LZO8*1G LZO8*2G LZO8*3G LZOD*1D Service Instructions 11 - Bubbler Lower and Upper Shroud Assembly To access the refrigeration system and plumbing connections, remove four screws from bottom of cooler to remove the lower shroud. To remove the upper shroud for access to the pushbars, regulator, solenoid valve or other components located in the top of the unit, remove lower shroud, disconnect drain, remove four screws from tabs along lower edge of upper shroud, unplug two wires and water tube.
- Page 6 LZO8*1G LZO8*2G LZO8*3G LZOD*1D Fig. 6 WATERSENTRY Filter Detail ® Detalle WATERSENTRY Filtro ® Description WATERSENTRY Filtrage ® WATERSENTRY FILTER PARTS LIST LISTA DE PIEZAS DEL FILTRO LISTE DES PIÈCES DU ® (See Fig. 6) (Vea la Fig. 6) FILTRE (Voir Fig. 6) ITEM NO.
- Page 7 FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.834.4816 IMPRESO EN LOS E.E.U.U. IMPRIMÉ AUX É.-U. REPAIR SERVICE INFORMATION TOLL FREE NUMBER 1.800.260.6640 ELKAY MANUFACTURING COMPANY • 2222 CAMDEN COURT • OAK BROOK, IL 60523 • 630.574.8484 Page 7 1000003094 (Rev. B - 11/16)
