- Page 1 VIDAR NDTPRO Industrial Film Digitizer Installation Guide For Use with Windows 7, 8, & 10 (Serial Numbers 370,000 to 379,999)
- Page 2 © Copyright November 2019 by VIDAR Systems Corporation. All rights reserved. Sales: 1-800-471-7070 or 365 Herndon Parkway 1-800-471-7226 Herndon, VA 20170 U.S.A. Email: order@3dsystems.com Phone: 1-703-471-7070 Technical Support: Fax: 1-703-471-7665 1-800-471-7070 or 1-703-471-7070 Internet: www.vidar.com E-mail: medtech@3dsystems.com Emergo Europe E-mail: EmergoEurope@ul.com...
- Page 3 Product compliance testing was conducted using VIDAR shielded cables. Modifications to the digitizer or the VIDAR shielded cables or the use of cables other than those available from VIDAR could void the user’s authority to operate the equipment.
- Page 4 2.4 sq. in (15.5 sq. cm). Light from the LED illuminator may be indirectly observed in the digitizer’s film entry and exit areas. 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
-
Page 5: Table Of Contents
1. Apply Power to the Digitizer ..................21 2. About the VIDAR Drivers ..................22 3. Install the VIDAR Drivers ..................22 Appendix: Electromagnetic Guidance ................. 29 Appendix: Symbols ....................... 33 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide... -
Page 6: Intended Use
Intended Use The NDTPRO Industrial Film Digitizer is intended for making digital copies of x-ray films for non- destructive testing applications. This device is not intended for medical use. 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide... -
Page 7: Unpack
If the carton is damaged: Notify the shipper immediately. Take photographs of the damage. Send pictures and description of damage to: medtech@3dsystems.com. Notify VIDAR Support at 1-703-471-7070. 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide... -
Page 8: Unpack The Shipping Carton
Failure to properly pack, or failure to use VIDAR authorized shipping materials, will void the product’s warranty, and will likely result in costly repairs. -
Page 9: Unpack The Accessory Box
Failure to properly pack, or failure to use VIDAR authorized shipping materials, will void the product’s warranty, and will likely result in costly repairs. -
Page 10: Unwrap
Exit tray the plastic bag surrounding the exit tray. Stand Accessory box 4. Unwrap a. Unwrap all items. b. Remove the foam block from the rear of the digitizer base: 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide... -
Page 11: Identify The Components
Power cord: 115V (p/n 4043-001) or 230V (p/n 2104-006) Quick setup card USB cable: 6 foot (p/n 4618) VIDAR NDTPRO Industrial Film Digitizer CD Digitizer Base Exit Tray Film Support bar Stand Film Feeder 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide... -
Page 12: If Anything Is Missing
6. If Anything Is Missing... Immediately contact your VIDAR supplier. 7. Activate Your Product Warranty a. Locate the “Warranty information card” form on the NDTPRO Industrial Film Digitizer CD. b. Print the “Warranty information card.” c. In the “Product information” section, record this information: ... -
Page 13: Setting Up
Setting Up The digitizer must be placed on a counter or tabletop. SAFETY WARNING Never place the digitizer on the floor. 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide... -
Page 14: Identify Important Features
Press I to turn power ON. Switch— Press 0 to turn power OFF. Factory use USB Port ON/OFF Switch Power switch and power entry module Power Entry module Digitizer base, rear view 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide... -
Page 15: Assemble The Digitizer
Front view Side view Thumbscrews (2) Longer portion toward front *Vent in bottom of base must be over cutout in stand 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide... - Page 16 Also note the connector on the bottom of the feeder. It mates to the connector on top of the digitizer base. Top ends of long screws Feeder, rear view Long screw Short screw Long screw Feeder, bottom view Connector 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
- Page 17 You may need to move the feeder slightly to get the screws started in the holes. Tighten each screw a few turns, then repeat until all are finger tight. 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
- Page 18 4. Install the exit tray by hooking it over the notched plastic edge just below the rollers. When the exit tray is properly positioned, it will be parallel to the roller shaft. Roller shaft Exit tray Properly installed exit tray 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
- Page 19 Avant de commencer la connexion, assurez vous que votre ordinateur soit bien éteint. Advertencia Antes de continuar con la instalación, favor de apagar su computadora y periférico. Warnung Vor dem Installieren den Computer und angeschlossene Geräte ausschalten. 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
-
Page 20: Connect The Power Cord
Note: The film digitizer has an auto-sensing power supply. When you apply power, the digitizer will detect the voltage and set itself for proper operation. NEXT: “Device Driver Installation” 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide... -
Page 21: Device Driver Installation
ON/OFF Switch Power switch and power entry module Power Entry module c. Wait for all three LEDs on the front of the digitizer to turn green. Digitizer base, rear view 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide... -
Page 22: About The Vidar Drivers
PC. Wait until you are prompted to connect the digitizer to the PC. b. Turn on the PC. c. Insert the VIDAR NDTPRO Industrial Film Digitizer CD into the CD-ROM drive. Browse to the CD and double-click on 19090-003 VIDAR_Driver_6.1 Online Install Package.exe on the CD to install the driver. - Page 23 In the first screen, click Next >. e. In the License Agreement screen, activate I accept the terms of the license agreement, then click Next >. 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
- Page 24 In the Ready to Install the Program screen, click Install. g. The Setup Status screen will appear. Wait while the files are installed. 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
- Page 25 When installing on Windows 7, 8, & 10, 64 bit the name will appear as Jungo i. When installing on Windows 7, 8, & 10, 32 bit the name will appear as VIDAR j. InstallShield will indicate that installation is complete. However, the driver installation is not complete.
- Page 26 VIDARINFO icon. m. The window shown below will appear. This indicates that the digitizer is communicating with the computer. n. Click “OK” if the Digitizer Information is present on the Screen. 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
- Page 27 The serial number will not report if the digitizer was just powered on. The digitizer is now ready to operate. Please refer to the “User’s Guide for VIDAR NDTPRO Digitizers” found on the VIDAR NDTPRO Industrial Film Digitizer CD for operating instructions.
- Page 28 When using Window 7, 8, & 10 64 Bit OS the Digitizer is listed under Jungo When using Window 7, 8, & 10 32 Bit OS the Digitizer will be listed under Imaging Devices 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
-
Page 29: Appendix: Electromagnetic Guidance
The Digitizers are suitable for use in all establishments other than CISPR11 domestic and those directly connected to the public low voltage Class A power supply network that supplies buildings used for domestic purposes. 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide... - Page 30 Guidance And Manufacturer’s Declaration – Electromagnetic Immunity Enclosure Port The VIDAR NDTPRO Industrial Film Digitizer is intended for use in the electromagnetic environment specified below. The customer or end user of the Digitizer should assure that it is used in such an environment.
- Page 31 While communication might not be possible when ME EQUIPMENT that includes radio equipment is tested in its bandwidth, the ME EQUIPMENT or ME SYSTEM shall still be able to provide its BASIC SAFETY and ESSENTIAL PERFORMANCE. 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
- Page 32 Table A- Test specifications for Enclosure Port immunity to RF wireless communications equipment. The customer or the user of the VIDAR NDTPRO Industrial Film Digitizer can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the Digitizer as recommended below, according to the maximum output power of the communications equipment.
-
Page 33: Appendix: Symbols
For more information about where you can dispose of your waste equipment for recycling please contact your local city office, your household waste disposal service or the shop where you purchased the product. 19440-001 Rev. E VIDAR NDTPRO Industrial Film Digitizer Installation Guide... - Page 34 365 Herndon Parkway Herndon, VA 20170 Phone: +1.703.471.7070 Fax: +1.703.471.7665 Web: www.vidar.com Technical Support: +1.703.471.7070 Phone: +1.800.471.7226 +1.703.471.7665 Email: medtech@3dsystems.com...
