VIDAR NDTPRO
Industrial Film Digitizer
Installation Guide
For Use with Windows 7 & Windows 8
(Serial Numbers 370,000 to 379,999)
P/N 19440-001, Rev C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NDTPRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VIDAR NDTPRO

Summary of Contents for VIDAR NDTPRO

  • Page 1: Vidar Ndtpro Industrial Film Digitizer Installation Guide

    VIDAR NDTPRO Industrial Film Digitizer Installation Guide For Use with Windows 7 & Windows 8 (Serial Numbers 370,000 to 379,999) P/N 19440-001, Rev C...
  • Page 2 © Copyright 2017 by VIDAR® Systems Corporation. All rights reserved. Terms denoted by the trademark symbol ( or ®) used in this publication are trademarks or service marks registered in the United States or other countries. 365 Herndon Parkway Sales: 1-800-471-7226 Herndon, VA 20170 U.S.A.
  • Page 3 Product compliance testing was conducted using VIDAR shielded cables. Modifications to the digitizer or the VIDAR shielded cables or the use of cables other than those available from VIDAR could void the user’s authority to operate the equipment.
  • Page 4 2.4 sq in (15.5 sq cm). Light from the LED illuminator may be indirectly observed in the digitizer’s film entry and exit areas. 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 5: Table Of Contents

    Assemble the Digitizer ....................15 Connect the Power Cord ..................... 20 VIDAR NDTPRO Industrial Film Digitizer Device Driver Installation Guide ....21 Install Device Drivers for Windows 7 & 8 ..................22 1. Apply Power to the Digitizer ..................22 About the VIDAR Drivers ....................

  • Page 6: Intended Use

    Intended Use The NDTPRO Industrial Film Digitizer is intended for making digital copies of x-ray films for non- destructive testing applications. This device is not intended for medical use. 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 7: Unpack

    If the carton is damaged: Notify the shipper immediately.  Take photographs of the damage.  Send pictures and description of damage to: medtech@3dsystems.com.  Notify VIDAR Support at 1-703-471-7070.  19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 8: Unpack The Shipping Carton

    Failure to properly pack, or failure to use VIDAR authorized shipping materials, will void the product’s warranty, and will likely result in costly repairs.

  • Page 9: Unpack The Accessory Box

    Failure to properly pack, or failure to use VIDAR authorized shipping materials, will void the product’s warranty, and will likely result in costly repairs.

  • Page 10: Unwrap

    Exit tray the plastic bag surrounding the exit tray. Stand Accessory box 4. Unwrap a. Unwrap all items. b. Remove the foam block from the rear of the digitizer base: 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 11: Identify The Components

    Power cord: 115V (p/n 4043-001) or 230V (p/n 2104-006)  Quick setup card  USB cable: 6 foot (p/n 4618)  VIDAR NDTPRO Industrial Film Digitizer CD Digitizer Base Exit Tray Film Support bar Stand Film Feeder 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 12: If Anything Is Missing

    6. If Anything Is Missing... Immediately contact your VIDAR supplier. 7. Activate Your Product Warranty a. Locate the “Warranty information card” form on the NDTPRO Industrial Film Digitizer CD. b. Print the “Warranty information card.” c. In the “Product information” section, record this information: ...

  • Page 13: Setting Up

    Setting Up The digitizer must be placed on a counter or tabletop. SAFETY WARNING Never place the digitizer on the floor. 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 14: Identify Important Features

    Press I to turn power ON. Switch— Press 0 to turn power OFF. Factory use ONLY! USB Port ON/OFF Switch Power switch and power entry module Power Entry module Digitizer base, rear view 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 15: Assemble The Digitizer

    Front view Side view Thumbscrews (2) Longer portion toward front *Vent in bottom of base must be over cutout in stand 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
  • Page 16 Also note the connector on the bottom of the feeder. It mates to the connector on top of the digitizer base. Top ends of long screws Feeder, rear view Long screw Short screw Long screw Feeder, bottom view Connector 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
  • Page 17 You may need to move the feeder slightly to get the screws started in the holes.  Tighten each screw a few turns, then repeat until all are finger tight. 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
  • Page 18 4. Install the exit tray by hooking it over the notched plastic edge just below the rollers. When the exit tray is properly positioned, it will be parallel to the roller shaft. Roller shaft Exit tray Properly installed exit tray 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
  • Page 19 Avant de commencer la connexion, assurez vous que votre ordinateur soit bien éteint. Advertencia Antes de continuar con la instalación, favor de apagar su computadora y periférico. Warnung Vor dem Installieren den Computer und angeschlossene Geräte ausschalten. 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 20: Connect The Power Cord

    Note: The film digitizer has an auto-sensing power supply. When you apply power, the digitizer will detect the voltage and set itself for proper operation.  “Device Driver Installation Guide” NEXT: 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 21: Vidar Ndtpro Industrial Film Digitizer Device Driver Installation Guide

    VIDAR NDTPRO Industrial Film Digitizer Device Driver Installation Guide 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 22: Install Device Drivers For Windows 7 & 8

    ON/OFF Switch Power switch and power entry module Power Entry module Digitizer base, rear view c. Wait for all three LEDs on the front of the digitizer to turn green. 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 23: About The Vidar Drivers

    PC. Wait until you are prompted to connect the digitizer to the PC. b. Turn on the PC. c. Insert the VIDAR NDTPRO Industrial Film Digitizer CD into the CD-ROM drive. Browse to the CD and double-click on 19090-003 VIDAR_Driver_6.1 Online Install Package.exe on the CD to install the driver.
  • Page 24 In the first screen, click Next >. e. In the License Agreement screen, activate I accept the terms of the license agreement, then click Next >. 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
  • Page 25 In the Ready to Install the Program screen, click Install. g. The Setup Status screen will appear. Wait while the files are installed. 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
  • Page 26 When installing on Windows 7 & 8 64 bit the name will appear as Jungo i. When installing on Windows 7 & 8 32 Bit the name will appear as VIDAR j. InstallShield will indicate that installation is complete. However, the driver installation is not complete.
  • Page 27 Click “OK” if the Digitizer Information is present on the Screen. The digitizer is now ready to operate. Please refer to the “User’s Guide for VIDAR NDTPRO Digitizers” found on the VIDAR NDTPRO Industrial Film Digitizer CD for operating instructions.
  • Page 28 When using Window 7 & 8 64 Bit OS the Digitizer is listed under Jungo When using Window 7 & 8 32 Bit OS the Digitizer will be listed under Imaging Devices 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 29: Appendix: Electromagnetic Guidance

    Table 201 The VIDAR NDTPRO Industrial Film Digitizer is intended for use in the electromagnetic environment specified below. The customer or end user of the Digitizer should assure that it is used in such an environment. Emissions test...
  • Page 30 Guidance And Manufacturer’s Declaration – Electromagnetic Immunity Table 202 The VIDAR NDTPRO Industrial Film Digitizer is intended for use in the electromagnetic environment specified below. The customer or end user of the Digitizer should assure that it is used in such an environment.
  • Page 31 Guidance And Manufacturer’s Declaration – Electromagnetic Immunity Table 204 The VIDAR NDTPRO Industrial Film Digitizer is intended for use in the electromagnetic environment specified below. The customer or end user of the Digitizer should assure that it is used in such an environment.
  • Page 32 NOTE 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies. NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...

  • Page 33: Appendix: Symbols

    For more information about where you can dispose of your waste equipment for recycling please contact your local city office, your household waste disposal service or the shop where you purchased the product. 19440-001 Rev. C VIDAR NDTPRO Industrial Film Digitizer Installation Guide...
