I.D. AL My Music Player Quick Start Manual

I.D.AL - My Music Player - MP3 and WAV audio player - Quick Start guide
1 - Connections
1 2 3 4
1 - USB Host connexion. Connect USB flash memory, USB hard disk
2 - USB Device link to connect a computer
3 - Button 1 and 2
4 - LCD display
5 - SD card memory slot
6 - Infrared sensor
7 - «DATA» encoder
8 - Power on/off
2 - SD and USB stick memory
Choose a quality flash memory card of minimum size 256MB up to 64GB - Formatted in FAT32 only
Compatible with major USB Key or SD / SDHC card
3 - Operation of the My Music Player
You need to create some folders to use the My Music Player. At
minimum, you need to place one folder at root with the name «MUSIC».
Inside this folder, place one sub-folder «MUS001». and your audio file
inside.
When you have created the folders and copied the files, insert the
media in the player and switch on.
5 - Play a folder
My Music Player need 30 seconds to start. After boot, you can see a
welcome message with the name, serial number and firmware version.
My music player My music player My music player My music player My music player
SN:8bxx V1610 SN:8bxx V SN:8bxx V SN:8bxx V SN:8bxx V 1610 1610 1610 1610
Press Data button and turn
USER USER Source Source
USER USER -> Source USER Source -> SELECT SOURCE Source
PLS PLS/ / / / / SP SP SP SP SPT T T T T -> MUS PLS MUS MUS
PLS PLS MUS MUS -> 001
Turn and select «1» and press the data button. You should listen the
files in the folder MUS001.
® Waves System - La Ville en Bois - 44830 BOUAYE - FRANCE - Tel : +33 (0) 2 40 78 22 44 - www.id-al.com - V1610
My Music Player - Quick start guide
5 6 7 8
SELECT SOURCE SELECT SOURCE
SELECT SOURCE SELECT SOURCE -> MUS
001 001 RND RND
001 001 -> RND RND RND
9
9 - Power supply input
10 - RS232 link
11 - Ethernet link
12 - Aux audio input
13 - Unbalanced audio output
14/15 - Balanced audio output
4 - First use
When you switch on for the first time, My Music Player ask you to
select the main media. Main Media is the main storage disk (USB stick,
SD card, HDD) where you have placed the audio files.
+MAIN MEDIA
no media
USB-EXT
USB-INT
SD CARD
Click on DATA button to select the function
Turn the button to make your choice
Click the button to validate
6 - Use Ethernet
Connect My Music Player using Ethernet to setup date/time and some
other parameters.
If you don't know the IP address of the player (DHCP mode as default),
you can use the name of the player.
In your browser, type the name : http://mmp-xxxx
xxxx = the serial number of your player you can see on the LCD when
MUS/ / / / / MUS MUS
MUS
switch on in stop mode.
10 11 12 13
Select external USB connector
Select the internal USB
Select SD card in the front face
14 15
