Page 1: Instruction Manual
Instruction Manual 7" WATERPROOF REAR VIEW MONITOR RVS-9910 VEHICLE SAFETY - IT'S ALL WE DO. -
Page 2: Table Of Contents
Table of Contents Before Beginning Installation ..............Installation Guide ..................Wiring Camera & Monitor ................. Installation Diagram ................... Installing the Monitor ................Monitor Operation..................Splitting & Splicing ................... Monitor Dimensions ................. Monitor Specifications ................Trouble Shooting ..................13... -
Page 3: Before Beginning Installation
Before Beginning Installation Before drilling please check that no cable or wiring is on the other side of the wall . Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. -
Page 4: Installation Guide
Installation Guide Monitor 1. To attach the pedestal mount to the dashboard or to the headli n er use self-tapping screws and/or the adhesi v e pad. 2. Attach monitor to mount, and adjust mounting angle to allow optimum driver viewing comfort . (see fi gure 1.1 on page 8) - Page 5 Installation Guide The Power Harness. larly be triggered (i.e. side cam- eras can be triggered by the turn • To power the system connect signals etc.) the power(RED) 12V+wire to ignition power and the ground • To automatically have camera (BLACK) wire to chass is groun d.
-
Page 6: Wiring Camera & Monitor
Wiring Camera & Monitor • There is a built-in voltage • Audio:There is audio on channels 2 and 3. On channel 3 regulator for our systems which the blue trigger wire must be can handle 12-24 volts. Real energized (12V) to activate the consumption is 10 to 30 Volts. -
Page 7: Installation Diagram
Installation Diagram Figure 1.1 Figure 1.2 < --- t •-- :> t - - - S> <---11 Figure 1.3 Connection of U Bracket... -
Page 8: Installing The Monitor
Installing the Monitor Camera (Sold Separately) -
Page 9: Monitor Operation
Monitor Op e ration DOWN CAMERA ARROW SELECTION MENU/ SELECTION ARROW BUTTON ROTATE POWER IMAGE " ' ----i ' ON/OFF (Back/Exit when in �88��� • Menu Mode) MENU Brightness • Use "BRIGHTNESS" "CONSTRAST" "SATURATION' "SHARPNESS" to Contrast adjust the image properties. Saturation •... -
Page 10: Splitting & Splicing
Sun Shade INSTALLING • Installing sun s hade: Put shade cover on the display, make four corners tight • Installing back cover: Put the monitor with shade cover in the back cover (only for embedded monitor) shade-- • Splitting sun shade: Take the monitor on the left hand detach by right hand as indicated by the white arrow (see below) shade-a--... -
Page 11: Monitor Dimensions
Monitor Dimensions 205.50 mm -::==::: 'CJDDDDD ;--... -
Page 12: Monitor Specifications
Monitor Specifications 7" Waterproof LCD Monitor Video input Screen size 7" Picture display format 16:9 Resolution 800X 3(RGB)X 480 Contrast 500: 1 IP69 Waterproof ratin 300cd/ m2 Brightness Power �2W 700mA Current Operation temperature -20-+?0'C Storage temperature -30-+85'C Operating Power 12V- 24V System Auto matic PAL/NTSC... -
Page 13: Troubleshooting
Troubleshooting Monitor Displays Blue Screen & Displays No Signal t rigger on power harness is put to Do a hard reset, unplug all • power 12v+. cables and power cables leave If the problem still persists, verify out for 1 minute and then that alternate ports work. - Page 14 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 VEHICLE SAFETY - IT'S ALL WE DO.
