RVS -77555 Instruction Manual

1080p hd 360 camera system with built-in recording
Hide thumbs Also See for RVS-77555:
Table of Contents

Advertisement

Quick Links

Instruction Manual

1080P HD 360° CAMERA SYSTEM
WITH BUILT-IN RECORDING
RVS-77555
VEHICLE SAFETY -
IT'S ALL WE DO.
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RVS-77555 and is the answer not in the manual?

Questions and answers

Related Manuals for RVS RVS-77555

Summary of Contents for RVS RVS-77555

  • Page 1: Instruction Manual

    Instruction Manual 1080P HD 360° CAMERA SYSTEM WITH BUILT-IN RECORDING RVS-77555 VEHICLE SAFETY - IT'S ALL WE DO.

  • Page 2: Table Of Contents

    Table of Contents 1. Precautions........................3 2. Features..........................5 3. Standard Configuration....................6 4. Specifications........................7 5. Wiring Diagram....................... 8 6. Operation Instruction....................... 9 6.1 Remote Control....................... 9 6.2 User Interface Setup....................... 10 7. System Contents......................25 8. Installation/Calibration....................26 9. WebApp Operating Instructions..................35 10.

  • Page 3: Precautions

    1. Precautions Storage and Keeping 1. Do not expose the System to excessive heat or cold. The storage temperature of this device is -30~+80°C, and the operating temperature is -20~+70 °C. The humidity is RH 90%. 2. Never use this device near a bathtub, wash basin, kitchen, damp basement, swimming pool or similar places.
  • Page 4 Maintenance 1. Remove all the cable connections from the control box before cleaning the device. 2. Use a mild household detergent and clean the unit with a slightly damp, soft cloth. 3. Never use strong solvents such as thinner or benzine, as they might damage the finish of the device.

  • Page 5: Features

    2. Features 2.1 Basic Features 1. 4 pcs. 190° Full HD 1080P wide-angle fish-eye cameras, horizontal view angle>170°, Maximum of 8CH inputs. 2. Techniques of dual-core ARM Cotex-A9 and SOC development of built-in high performance H.264 video encoding / decoding engineer core make it efficient to composite high accuracy seamless images.

  • Page 6: Standard Configuration

    2.3 Features 1. Panoramic image. 2. Blending seamless stitching. 3. 360° view. 4. Auto switch to reversing image when reverse wire is triggered. 5. Auto switch to left / right image when left / right wire is triggered. 6. Installation guide with pictures. 7.

  • Page 7: Specifications

    4. Specifications 1. Main Control Box 2. Camera Parameter Vehicle Safety - It's All We Do.

  • Page 8: Wiring Diagram

    5.Wiring Diagram Rear View Safety...

  • Page 9: Operation Instruction

    6.Operation Instruction 6.1 Remote Control • MENU: (ENTER / MENU) Enter into main menu or confirm menu selection. • SYS: (ESC) Exit main menu interface / return to main menu interface. • V- / V+: (LEFT, RIGHT) Left, right / Decrease, Increase button. Shift image channel to left / right view, or operate plus / minus in main menu interface.

  • Page 10: User Interface Setup

    6.2 User Interface 6.2.1 User Administration Feature Description: 1) Input password. 2) Login confirmation. 3) Change Password 4) Return to last menu Note: Initial password: 000000. Please modify password after stitching is finished. If password is forgotten, input “root” to log in. Select factory default setting in Information menu and new password will be 000000 The operation period lasts for 10 min after login.
  • Page 11 Setting Description: Current password New Password Input new password again Save password Return to last menu 6.2.2 Main menu interface Feature Description: System: Basic function setting. Clock: System time setting. Storage: Storage function and system log management. DVR: Recording function configuration. AVM: 360 panorama calibration and related operation.
  • Page 12 6.2.3 System Setup Feature Description: Standby Delay: Time frame can be set for standby. AV: PAL / NTSC .Correspondent video output format is 1080P / 50 frames or 1080P / 60 frames. Full Panel AVS: Button for full screen / panoramic display. Temporarily unavailable. Surround View Region: Surround view size selection.
  • Page 13 6.2.4 Clock Setup Feature Description: Set calendar time. Save setup time. Exit menu and return to the main menu. Menu setting change must be saved to become 6.2.5 Storage Feature Description: Format SD Card or U Disk. Select all system log files Vehicle Safety - It's All We Do.
  • Page 14 Unselect all system log files. Clear all old system log files. Export the selected system log file. Exit the Storage interface and return to the main menu. Note 1) When the U Disk and SD Card work abnormally, there will be a cursor prompt on the panorama display interface and Storage menu interface.
  • Page 15 Power on automatic video recording function setting. Save setting parameters. Exit the DVR interface and return to the main menu. If any parameter is modified, it must be saved before exit, otherwise the modification is invalid. Note: When parameters are modified, saving or exit will prompt to restart. 6.2.7 AVM Calibration Feature Description: Length / Width / Chess Position / Grid Size: Panoramic stitching parameters.
  • Page 16 Soft Keyboard Feature Description: Exit editing. Delete input. Capital shift. Letter lock. Note: Letter lock is locked by default. Unlock to input characters. Letter can only be input via soft keyboard. Chess Board Feature Description: Layout setting of calibration cloth. Save.
  • Page 17 AVM Option Setup Feature Description: Upload calibration files of U Disk to system. Output saved calibration files and 4CH single-view to U Disk. Change vehicle models. Exit Key: Get back to AVM Calibrate interface. Note: Calibration file applies XML extension. Vehicle Safety - It's All We Do.
  • Page 18 Upload Calibration Files Feature Description: Select uploaded files with XML extension. Confirm selected files with XML extension. Note: If the preference of uploaded file is empty, please select files with XML extension from the expand list. Once the change of XML files confirms, you are to be prompted to restart the system either save or exit. Output Calibration Files and 4CH Single-view Images Rear View Safety...
  • Page 19 Setting Description: Confirm output files. Note: Before output, make sure U Disk is connected and functioning normally. U Disk shouldn't be pulled out during processing. After successfully output files, name it with the time and date of the system. Change Vehicle Models Feature Description: Select vehicle models.
  • Page 20 6.2.8 Player Interface Feature Description: Calendar list: Green highlighted dates represent video files of current date. Press return key to get back to player interface. Time list: Green represents video files of current time. Press cancel key to get back to calendar 3) Video list and control key: All / none / delete / export / play key to operate video settings.
  • Page 21 Note: 1) If the system is recording video, you will be prompted to close the recording before entering player. Please note the timing for player. Recording will be automatically recovered once exits the player. 2) System can only search and play videos recorded 3 months before the system's current date. Playback Interface Feature Description: Control button and progress bar for playback.
  • Page 22 6.2.9 Information 1) APP Version: Current APP Flash version information / upgrade files list / upgrade confirmation key. This function is activated only when there's APP upgrade file HD360-CPU-APP-00-Vx.x.xx.tar.gz under U Disk root file. 2) Firmware Version: Current MCU Firmware version information / upgrade files list / upgrade confirmation key.
  • Page 23 6.2.10 Radar Setup Channel and Sensors: Each channel uses 3 sensors. Red sign flickers when sensor detects any obstacle in the range. If combine-select currently edited locations of radar sensor, their rep- resented red blocks will flicker. Select on to enable sensor to work and off to disable. Detection range is configurable from 0.6m to 5m.
  • Page 24 Tips for Installation and Calibration of 360 System The mats need to match with the vehicle size. For example, the vans or other similar-sized/smaller-sized vehicles should be calibrated with the 20CM chess-board mats. The trucks or similar-sized/larger-sized vehicles should be calibrated with the 40CM chess-board mats.

  • Page 25: System Contents

    7. System Contents Control box Camera Remote Control Power Cable Main Wire Bundle IR Extension Cable 1080P HD Monitor Camera Extension Cable HDMI Adapter Cable WEBAPP Transmitter Vehicle Safety - It's All We Do.

  • Page 26: Installation/Calibration

    8. Installation Steps Step 1: Wiring • Start wiring from the camera to the main unit of 360 system; • The main unit is usually put in the central control room or behind the tool box. Step 2: Installing cameras •...
  • Page 27 Step 3: Installing Cameras • Adjust camera angle one by one. Then screw it tightly. • Make sure the original image mark (white dot on cameras) are placed outward; • Proper angle of cameras Vehicle Safety - It's All We Do.
  • Page 28 Step 4: Install the main unit • The main unit is usually put in the central control room or behind the tool box. Step 5: Check the wiring connection before powering on • Make sure all cables are well connected before powering on. Step 6: Check basic function of the system •...
  • Page 29 Step 2: Lay calibration mats • Make sure each mat could be completely shown in the according single view. • Mats in the front/back should be laid in the middle as the front/back cameras are mostly installed in the middle. •...
  • Page 30 Step 3: Enter “AVM calibrate” • Input calibration figures of Length, width, cheese position (in cm); • Grid size is 40 cm by default for large vehicle system, 20 cm by default for small vehicle system. You could also use other mats and set up the grid size accordingly; •...
  • Page 31 Step 4: Indicating information • On the bottom of the screen, info will be shown indicating the calibration state; • For every channel, there are 3 states: 1) Three Chess board found, calibrate one step, 2) One chess board found, calibrate exit only, 3) No chess board found.
  • Page 32 Calibration Mat Chosen and Laid Rear View Safety...
  • Page 33 Calibration Mat Chosen and Laid (Continued Table 1) Vehicle Safety - It's All We Do.
  • Page 34 Calibration Mat Chosen and Laid (Continued Table 2) Rear View Safety...

  • Page 35: Webapp Operating Instructions

    9. WebAPP Operating Instructions 9.1 Preparation • 360 control has internal wifi, and wifi antenna is connected. • This Web UI function does not support IOS system, please use mobile phone with android system to access. • Access must be done using the Google browser. Because this Web UI is developed based on the rendering engine of Google browser, some built-in phone browsers or other types of browsers may not support the responsive function well.
  • Page 36 9.3 Features 9.3.1 Video Files Download Feature Description: Select the "+" or "-" icon at the far right of the menu bar to open or close the video download page. 2) Calendar list: Yellow highlighted dates represent video files of current date. Only dates in yellow could be selected.
  • Page 37 Retrieve all valid video files for the selected time period. Select all video files in the list. Download all selected video files. Note: 1) The download function is only available when there is video file in the 360 round view system. In other words, the SD card must be inserted and there is video file in the SD card.
  • Page 38 9.3.3 AVM Calibrate Feature Description: Panorama stitching parameter settings. This function is equal to the “AVM Calibrate” interface on the system interface. Rear View Safety...
  • Page 39 9.3.4 DVR Setup Feature Description: Recording function related settings. The function is equal to the system’ s “DVR Setup” interface. 9.3.4 Version Import And Export Vehicle Safety - It's All We Do.

  • Page 40: Faqs

    FAQs Q1: After the stitching, why don't certain area in front / back / left / right area show any image? 1. Please make sure the calibration lines and cloths are laid properly. 2. Press up / down / left / right button to shift single-view channel and make sure that all cameras are functioning normally and surrounding landscapes don't turn upside down or left / right reversion.
  • Page 41 NOTES Vehicle Safety - It's All We Do.
  • Page 42 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Vehicle Safety - It's All We Do.
