Page 1: Table Of Contents
All manuals and user guides at all-guides.com AH 530-790 AH 530-720 Preface Safety notes Page 3 1. Important notes Page 4-5 1.1 For your safety Page 4 1.2 Operating for the first time Page 5 1.3 About use Page 5 2. -
Page 2: Preface
All manuals and user guides at all-guides.com Preface With your new extractor hood, working in the kitchen will be even more fun. The appliance offers you a number of advantages: – A good extraction capacity with low noise values, – a large number of control functions, –... -
Page 3: Safety Notes
All manuals and user guides at all-guides.com Safety notes Read And Save These Instructions. WARNING - TO REDUCE THE RISK OF FIRE, WARNING - TO REDUCE THE RISK OF INJURY ELECTRIC SHOCK, OR INJURY TO PERSONS, TO PERSONS IN THE EVENT OF A RANGE OBSERVE THE FOLLOWING: TOP GREASE FIRE, OBSERVE THE FOLLOWING:... -
Page 4: Important Notes
All manuals and user guides at all-guides.com 1. Important notes 1.1 For your safety – Damaged appliances must not be operated. – Isolate the appliance from the mains during every maintenance operation. To do this, actuate – The appliance must only be connected by an the corresponding fuse. -
Page 5: Operating For The First Time
If the problem has nothing to time. do with the power supply, please contact your specialist dealer or your local Gaggenau after- – The rating plate for this appliance is included sales service. with the instructions on a separate sheet. Store the rating plate in the same location as your operating and assembly instructions. -
Page 6: Features
All manuals and user guides at all-guides.com 2. Features 1 Outgoing air duct 2 Control panel 3 Grease filter 4 Lighting Fig. 2 Installation accessories: Stainless steel-design ventilation duct: LK 530-010 for ceiling heights of 7 ´ ´ 3 ´ ´ - 8 ´ ´ 6 ´ ´ / 2.20 - 2.66 m LK 530-020 for ceiling heights of Grease filter 8 ´... -
Page 7: Operation
All manuals and user guides at all-guides.com 3. Operation The AH 530-790 is 35 ´ ´ / 90 cm wide, and the AH 530-720 is 47 ´ ´ / 120 cm wide. Operation of both extractor hoods is identical. After they have been pressed, all functions selection keys except 0 (“Motor off”) are backlit in... - Page 8 All manuals and user guides at all-guides.com The Int key for the intensive level should be pressed when browning and frying in an open pan (see Fig. 6). If you have switched on the hood by selecting the intensive level, it will be switched off again automatically after 5 minutes.
- Page 9 All manuals and user guides at all-guides.com Special functions: Intensive time: You can set the intensive level running time to 3, 5 or 10 minutes by simultaneously pressing the Int key and the 1, 2 or 3 key and you can store this setting (see Fig.
-
Page 10: Cleaning And Care
All manuals and user guides at all-guides.com 4. Cleaning and care Cleaning the grease filters The grease filter saturation display F flashes after an operating time of 30 hours to indicate that you should clean the grease filter (see Fig. 3). The grease filter can of course be cleaned at any time, even if the grease filter saturation display should not start to flash. - Page 11 All manuals and user guides at all-guides.com Cleaning the extractor hood Clean the extractor hood and the aluminium- design ventilation ducts (LK 530-011/021) with a soft cloth and mild detergent solution only. Clean the stainless-steel design ventilation ducts (LK 530-010/020) with mild detergent solution and apply stainless steel care agent to the metal surface using a soft cloth.
-
Page 12: Maintenance
If the power supply is functioning correctly, but your appliance still does not work, please contact your Gaggenau dealer who will provide you with the address and telephone number of your nearest manufacturer’s authorized service agent or contact Gaggenau USA on (800) 828-9165. -
Page 13: Assembly Instructions
All manuals and user guides at all-guides.com 6. Assembly instructions 6.1 Technical data AH 530-790: Weight: 23.5 kg Dimensions: 35 ´ ´ x 20 ´ ´ 898 x 550 mm AH 530-720: Weight: 27.5 kg Dimensions: 47 ´ ´ x 20 ´... -
Page 14: Installation
All manuals and user guides at all-guides.com 6.2 Installation The applicable regulations of the energy supply companies and the regional construction WARNING - TO REDUCE THE RISK OF FIRE, regulations must be observed when installing ELECTRIC SHOCK, OR INJURY TO PERSONS, the hood. - Page 15 All manuals and user guides at all-guides.com Flexible aluminium pipes, corrosion-protected The duct units listed below are available sheet metal pipes and exhaust air pipes whose depending on the height of the ceiling: material conforms to fire B1 in accordance with Stainless steel-design ventilation duct: DIN 4102 can be used.
- Page 16 All manuals and user guides at all-guides.com Important: Before marking the securing holes, 15 ( ") make sure that no electricity or water lines or other lines are laid at the drilling points in the wall. Proceed as follows: ") –...
- Page 17 All manuals and user guides at all-guides.com – Secure the hood on the wall with the four screws b (Fig. 21). – Establish the pipe connection. – Establish the electrical connection. – Stainless steel chimney only (LK 530-010/020): Pull the protective film off the chimney’s trims. Note: Avoid damaging the sensitive metal surfaces.
- Page 18 All manuals and user guides at all-guides.com Operating and assembly instructions AH 530-790 AH 530-720 Extractor hood...
